nicRingSetSdPIdx
nicInterrupts
nicSendThresholdHit
Phy CRC counter

10.84 txcfg

Command: txcfg
Description: Configure protocol packets for transmission
Syntax: txcfg
Example:
0:> txcfg
1. Source MAC
2. Destination MAC
3. Length (14-65535)
4. Packet Type {Non(0),EthV2(1),802.3(2),SNAP(3)}: Ethernet II
5. Protocol Field {Non(0),IP(1),ARP(2),BRM(3)}
6. Source IP
7. Destination IP
8. IP Protocol Field { UDP(17), TCP(6) }
80. Source Port
81. Destination Port
9. IP Option Length (32-bit Words)
10. TCP Option Length (32-bit Words)
11. Pattern { As-is(0), Inc(1), Random(2), 0s(3), FFs(4),
AA55(5), 55AA(6),IP_Iden-Inc(7),Load from file(8)
00ff8(9) 00ff16(10), 00ff32(11), 00ff(12)}
...)
12. IP Checksum Offload{ YES(1), NO(0) }
13. TCP/UDP Checksum Offload { YES(1), NO(0) }
14. TCP/UDP Pseudo Checksum Only { YES(1), NO(0) }: NO
15. Insert VLAN Tag { YES(1), NO(0) }
16. VLAN Tag
17. Random IP header field { YES(1), NO(0) }
18. Random TCP/UDP header field { YES(1), NO(0) } : NO
0. Exit
Enter your choice (option=paramter) ->

10.85 rxcfg

Command: rxcfg
Description Configure RX parameters.
Syntax: rxcfg
Example:
0:> rxcfg
1. Host Loopback { Enable(1), Disable(0) }
2. Modify Rx Packet { Enable(1), Disable(0) }
3. Dump Rx Packet { None(1),Hex(2), Decode(3) }
4. Dump Rx Length
5. Tx Fragment Length
6. Tx Flags
: 0 nicRingStatusUpdate
: 0 nicAvoidedInterrupts
: 0
: 0
page 124
Broadcom Confidential and Proprietary
: 0
: 0
: 10:11:12:13:14:15
: 00:01:02:03:04:05
: 1514
: IP
: 10.2.1.1
: 10.2.1.2
: UDP
: 100
: 200
: 0
: 0
: Increment (00,01,02
: NO
: NO
: NO
: 1
: NO
: Disable
: Disable
: None
: 64
: 1518
: 0000
