STMicroelectronics STM32F038C6 Manual page 29

STM32F038x6
Pin number
30 19 19 C1
31 20 20 B1
32 21 - -
33 22 - -
34 23 21 A1
35 - - -
36 - - -
37 24 22 A2
38 25 23 -
39 26 24 -
40 27 25 -
Table 11. Pin definitions (continued)
Pin name
(function upon reset)
17 PA9
18 PA10
- PA11
- PA12
PA13
19
(SWDIO)
- PF6
- PF7
PA14
20
(SWCLK)
- PA15
- PB3
- PB4
Notes
I/O FTf -
I/O FTf -
I/O FT -
I/O FT -
(5)
I/O FT
I/O FTf -
I/O FTf -
(5)
I/O FT
(6)
I/O FT
(6)
I/O FT
(6)
I/O FT
DocID026079 Rev 3
Pinouts and pin description
Pin functions
Alternate functions
USART1_TX,
TIM1_CH2,
I2C1_SCL
USART1_RX,
TIM1_CH3,
TIM17_BKIN,
I2C1_SDA
USART1_CTS,
TIM1_CH4,
EVENTOUT
USART1_RTS,
TIM1_ETR,
EVENTOUT
IR_OUT,
SWDIO
I2C1_SCL
I2C1_SDA
USART1_TX,
SWCLK
SPI1_NSS,
I2S1_WS,
TIM2_CH_ETR,
EVENTOUT,
USART1_RX
SPI1_SCK,
I2S1_CK,
TIM2_CH2,
EVENTOUT
SPI1_MISO,
I2S1_MCK,
TIM3_CH1,
EVENTOUT
Additional
functions
-
-
-
-
-
-
-
-
-
-
-
29/102
32
