6.3.9

EMC characteristics

Susceptibility tests are performed on a sample basis during device characterization.
Functional EMS (electromagnetic susceptibility)
While a simple application is executed on the device (toggling 2 LEDs through I/O ports). the
device is stressed by two electromagnetic events until a failure occurs. The failure is
indicated by the LEDs:
●
Electrostatic discharge (ESD) (positive and negative) is applied to all device pins until
a functional disturbance occurs. This test is compliant with the IEC 61000-4-2 standard.
●
FTB: A Burst of Fast Transient voltage (positive and negative) is applied to V
V
SS
compliant with the IEC 61000-4-4 standard.
A device reset allows normal operations to be resumed.
The test results are given in
defined in application note AN1709.
Table 33.
Symbol
V
FESD
V
EFTB
Flash memory endurance and data retention
Parameter
Cycling (erase / write )
Program memory
Cycling (erase / write )
EEPROM data memory
Data retention (program memory) after
10 kcycles at T = 85 °C
A
Data retention (EEPROM data memory)
after 300 kcycles at T
A
Data retention (program memory) after
10 kcycles at T = 105 °C
A
Data retention (EEPROM data memory)
after 300 kcycles at T
A
through a 100 pF capacitor, until a functional disturbance occurs. This test is
Table
EMS characteristics
Parameter
Voltage limits to be applied on any I/O pin to
induce a functional disturbance
Fast transient voltage burst limits to be
applied through 100 pF on V
pins to induce a functional disturbance
