Table 14. Current consumption in Run mode, code with data processing running from RAM
Symbol Parameter
Supply current
in Run mode,
I
DD (Run
code executed
from
from RAM,
RAM)
Flash switched
off
1. Based on characterization, not tested in production, unless otherwise specified.
2. Oscillator bypassed (HSEBYP = 1 in RCC_CR register).
3. Tested in production.
50/109
Conditions
Range 3,
V
CORE
VOS[1:0] = 11
f = f
HSE HCLK
up to 8 MHz,
Range 2,
included
V
CORE
f = f /2
HSE HCLK
VOS[1:0] = 10
above 8 MHz
(2)
(PLL ON)
Range 1,
V
CORE
VOS[1:0] = 01
Range 2,
V
CORE
VOS[1:0] = 10
HSI clock source
(16 MHz)
Range 1,
V
CORE
VOS[1:0] = 01
MSI clock, 65 kHz
Range 3,
MSI clock, 524 kHz V
CORE
VOS[1:0] = 11
MSI clock, 4.2 MHz
Doc ID 17659 Rev 6
f
HCLK
1 MHz
=1.2 V 2 MHz
4 MHz
4 MHz
=1.5 V 8 MHz
16 MHz
8 MHz
=1.8 V 16 MHz
32 MHz
=1.5 V 16 MHz
=1.8 V 32 MHz
65 kHz
=1.2 V 524 kHz
4.2 MHz
STM32L151xx, STM32L152xx
(1)
Max
Typ
55 °C 85 °C 105 °C
200 300 300 300
380 500 500 500
720 860 860 860
0.9 1 1
1.65 2 2
3.2 3.7 3.7 3.7
2 2.5 2.5 2.5
4 4.5 4.5 4.5
7.7 8.5 8.5 8.5
3.3 3.8 3.8 3.8
7.8 9.2 9.2 9.2
40 60 60 80
110 140 140 160
700 800 800 820
Unit
µA
(3)
1
2
mA
µA
