Specifications

Thermal range:
Thermal accuracy:
Thermal uniformity:
Ramping speed:
Sample capacity:
Line voltage:
Frequency:
Power:
Fuses:
Displays:
Ports:
Memory:
–5° to 105°C, but no more than 30°C below ambient
temperature (4° to 100°C for the Slide Chambers Alpha unit)
±0.3°C of programmed target at 90°C, NIST-traceable
±0.4°C well-to-well within 30 seconds of arrival at 90°C
(for most Alpha units; see specifications for individual
Alpha units)
Up to 3°C/sec for all single- and dual-block Alpha units;
up to 1.2°C/sec for the Slide Chambers Alpha unit.
Varies with installed Alpha unit
DNA Engine
needed among voltages within these ranges)
50–60 Hz single phase
DNA Engine cycler: 850 W maximum
Two 6.3 A, 250 V, 5 x 20 mm
One 20 x 4 LCD alphanumeric display
One 25-pin 8-bit parallel interface printer port
One 9-pin RS-232 serial port for printer or remote use
One IEEE-488 bidirectional general purpose interface bus
400 typical programs in up to 12 individual folders
Tech Support: 1-800-4BIORAD • 1-800-424-6723 • www.bio-rad.com
Layout and Specifications
® cycler: 100–240 VAC rms (no adjustment
2-5
