Section 9 Product Information

Spare Parts

Catalog # Description
9204987 Door, Battery Compartment, gene gun
9204988 Cover, Molded Nose
9204995 External Barrel Handle
9101503 Screw, 6-32 x 1/4, FH
9100453 Thumbscrew, nylon, 1/4 x 20 x 1"
9100620 Thumbscrew, nylon, 1/4 x 20 x 1/2"
8004478 Assembly, C-shaft (tube support assembly)
9009712 Fuse, 5 x 20 mm, 0.125 A
9007296 Fuse, 5 x 20 mm, 0.25 A
9400359 Sealant, pipe
9109223 Fitting, elbow, female luer
9301185 Kit, helium regulator, soft goods (O-rings), version A
1652436 9 V Battery
1652423 Razor Blades, 10
1652416 O-rings, gene gun
1652417 Barrel Liner
1652426 Cartridge Holder

Gene Gun Specifications

Specifications
Physical
Dimensions Approximately 8 x 10"
Weight 3.15 lb
Construction Super epoxy or polycarbonate
Cylinder Acetal
Barrel liner Ryton
O-rings Viton
Electrical
Maximum current 10 mA peak
Voltage input 9 V DC alkaline battery, replaceable
Battery life 1,000 discharges in continuous use
Functional
Input pressure 600 psi maximum helium
Regulator relief pressure 700 ± 35 psi at regulator assembly
Regulator adjustment 800 psi limit maximum
Discharges 12 per cylinder revolution
Indexing Manual
Environmental
Operating 50–90°F (10–32°C) temp
30–80% humidity
Storage 32–140°F (0–60°C) temp
10–90 % humidity
