Select one of the displayed choices, then press «Proceed»:
• Yes accepts the step and displays the Enter Menu again. Use the Enter Menu to
enter the next step in the program.
• No allows reentry of the ramp rate and finish temperature.
• Option displays the Options Menu (see "Modifying a Program Step with the Options,"
p. 6-11).
4 Tip: A ramp step will not hold the block at its finish temperature. Instead, as soon as finish
temperature is reached, the next step of the program will immediately be executed. To
hold the block for some period of time at a ramp step's finish temperature, make sure a
temperature step immediately follows the ramp step, and program the hold at the finish
temperature into this step.

Entering a GoTo Step

To enter a GoTo step, select GoTo from the Enter Menu. The first GoTo screen will be
displayed:
The second line of this screen shows the number of the step being programmed (5 is used
in the example above). The last line of the screen allows entry of the number of the step
the program should cycle back to.
Enter the number of the step the program should cycle back to (1 is used in the
example below):
Press «Proceed». The step number will move to the second line of the screen, and a
line allowing an additional number of cycles to be entered will be displayed:
Tech Support: 1-800-4BIORAD • 1-800-424-6723 • www.bio-rad.com
Enter: CUSTO M 1
5=GoTo
GoTo s t e p : _
Enter: CUSTO M 1
5=GoTo
GoTo s t e p : 1
Enter: CUSTO M 1
3=GoTo 1
Addt n l c y c l e s : _
Creating Programs
6-13
