About the Instrument
Instrument Specifications
The table below lists the specifications for the instrument. All specifications listed
below are based on the following instrument settings:
Dispense/Wash rate:
Aspiration rate: 3
PARAMETERS
General
Display unit
Keyboard
Number of dispensing
channels
Manifold types
USB Interface
Variable
Volume of solution
dispensed
Dispensing accuracy
Dispensing uniformity
Residual volume
34
Note
Instrument specifications have been defined using Bio-Plex Pro flat
bottom microplates (Cat # 171025001), and may vary using other 96-well
plates.
250 µl/s/well
CHARACTERISTICS
Liquid Crystal Display with 2 rows of 16 digits
4-key membrane keyboard
Up to 4 channels
8 channel manifold
All connected devices must be approved and listed as per IEC 60950-1
Information Technology Equipment – Safety or equivalent local standards.
50 - 3000 µl in 50 µl increments for washing
50 - 400 µl in 50 µl increments for dispensing
<= 2 %
Measured under following conditions:
8-way manifold, 300 µl, dispensing rate 3 (250 µl/s/well), wash buffer, Bio-
Rad 96-well flat-bottom plates (Cat. # 171025001).
<= 4 % CV
Measured under following conditions:
8-way manifold, 300 µl, dispensing rate 3 (250 µl/s/well), wash buffer, Bio-
Rad 96-well flat bottom plates (Cat. # 171025001).
Measured under following conditions:
<= 4 µl / well, using Bio-Plex Pro flat-bottom plates and the recommended
preloaded programs. (Optimized for high bead recovery and low assay
%CVs.)
Bio-Plex Pro and Bio-Plex Pro II Wash Stations
