User Manual
Ascom d81 DECT Handset
Figure 12. Example of an Interactive Message
Mobile data from the handset can initiate the application to send the interactive message,
see

12.8 Mobile Data

action can be sending a message back to the application and/or dialling a specific number
etc.
12.8 Mobile Data
12.8.1 Send Mobile Data
It is possible to send predefined data from the handset by selecting a Service, see
Services on page 61. In addition, a short cut can be created for quick access to a Service, see
8.6 Short Cuts
Mobile data can be used for opening a door, starting/stopping a machine etc.
12.8.2 Send Mobile Data with a Prefix
Mobile data with a prefix is sent from the handset by pressing a pre-programmed Hot key or
Soft key or select a Service. Mobile data with prefix can be used to send information to an
application in the system.
The prefix is predefined by the user when programming the Service, see
page 61.

12.9 Send Data with Bluetooth Barcode Reader

The handset can be configured to receive data from a Bluetooth barcode reader and then
send the data to another destination. When the handset receives data, it is automatically
transmitted to the destination and is not stored in the handset. A dialog window "Message
sent" is displayed.
For more information about configuration, see Configuration Manual, Ascom d81 DECT
Handset, TD 92674EN. See also
user manual for the Bluetooth barcode reader.
08 June 2012 / Ver. D
Figure 11.
Conference this evening!
Will you be there?
"John Doe <John.Doe
@company.com
2011-01-23 12:00pm
Options
Reply
Select
on page 82. The user can then select one action from the list. The
on page 62
Pair/Connect Bluetooth Barcode Reader
Delete Close
Options
Back
TD 92644EN
8.5
8.5 Services on
on page 71, and
82
