Terminal Block Group

t062 [DigIn TermBlk 02] t063 [DigIn TermBlk 03]
t065 [DigIn TermBlk 05] t066 [DigIn TermBlk 06]
t067 [DigIn TermBlk 07] t068 [DigIn TermBlk 08]
Stop drive before changing this parameter.
Programmable digital input. Changes to these inputs takes effect as soon as they are entered. If a digital input is set for a selection that is only usable on one input, no other input can
be set for the same selection.
Options 0 "Not Used"
1 "Speed Ref 2"
2 "Speed Ref 3"
3 "Start Src 2"
4 "Start Src 3"
5 "Spd + Strt 2"
6 "Spd + Strt 3"
7 "Preset Freq"
(only for DigIn TermBlk 05...08)
8 "Jog"
9 "Jog Forward"
10 "Jog Reverse"
(1)
11 "Acc/Dec Sel2"
12 "Aux Fault"
13 "Clear Fault"
14 "RampStop,CF"
15 "CoastStop,CF"
16 "DCInjStop,CF"
17 "MOP Up"
18 "MOP Down"
(1)
19 "Timer Start"
(1)
20 "Counter In"
21 "Reset Timer"
22 "Reset Countr"
23 "Rset Tim&Cnt"
(1)
24 "Logic In 1"
(1)
25 "Logic In 2"
26 "Current Lmt2"
Terminal has no function but can be read over network communications with
Selects P049 [Speed Reference2] as drive's speed command.
Selects P051 [Speed Reference3] as drive's speed command.
Selects P048 [Start Source 2] as control source to start the drive.
Selects P050 [Start Source 3] as control source to start the drive.
[DigIn TermBlk 07] default.
Selects combination of P049 [Speed Reference2] and
drive.
Selects combination of P051 [Speed Reference3] and
drive.
[DigIn TermBlk 05] and [DigIn TermBlk 06] default.
• Selects a preset frequency in Velocity mode (P047, P049,
• Selects a preset frequency and position in Positioning mode (P047, P049,
[Step Units x].
Digital Inputs have priority for frequency control when programmed as Preset Speed and are active. See
IMPORTANT
Start Source and Speed Reference Selection on page 39
• When input is present, drive accelerates according to the value set in
[Jog Frequency].
• When input is removed, drive ramps to a stop according to the value set in
• A valid Start command will override this input.
[DigIn TermBlk 08] default.
Drive accelerates to A431 [Jog Frequency] according to
valid Start command will override this input.
Drive accelerates to A431 [Jog Frequency] according to
valid Start command will override this input.
If active, determines which Accel/Decel time will be used for all ramp rates except jog. Can be used with option 29 "Acc/Dec Sel3"
for additional Accel/Decel times. See A442
When enabled, an F002 "Auxiliary Input" fault will occur when the input is removed.
When active, clears an active fault.
Causes drive to immediately ramp to a stop regardless of how
Causes drive to immediately coast to a stop regardless of how
Causes drive to immediately begin a DC Injection stop regardless of how
Increases the value of A427 [MOP Freq] at the rate set in
Decreases the value of A427 [MOP Freq] at the rate set in
Clears and starts the timer function. May be used to control the relay or opto outputs.
Starts the counter function. May be used to control the relay or opto outputs.
Clears the active timer.
Clears the active counter.
Clear the active timer and counter.
Logic function input number 1. May be used to control the relay or opto outputs (t076,
Outx Sel], options 11...14). May be used in conjunction with StepLogic parameters
Logic function input number 2. May be used to control the relay or opto outputs (t076,
Outx Sel], options 11...14). May be used in conjunction with StepLogic parameters
When active, A485 [Current Limit 2] determines the drive current limit level.
Rockwell Automation Publication 520-UM001A-EN-E - February 2013
Related Parameter(s): b012, b013, b014, P045, P046, P048, P049, P050, P051, t064,
t086, A410-A425, A427, A431, A432, A433, A434, A435,
A442, A443, A488, A535, A560, A562, A563, A567,
b013
P048 [Start Source 2] as speed command with control source to start the
P050 [Start Source 3] as speed command with control source to start the
P051 [Speed Referencex] = 1...15). See
P051
for more information.
A432 [Jog Accel/Decel] and ramps to the value set in
A432
A432 [Jog Accel/Decel] and ramps to a stop when input becomes inactive. A
A432 [Jog Accel/Decel] and ramps to a stop when input becomes inactive. A
[Accel Time 2] for more information.
P045 [Stop Mode] is set.
P045 [Stop Mode] is set.
P045 [Stop Mode] is set.
A430 [MOP Time].
A430 [MOP Time].
Programming and Parameters Chapter 3
[Contrl In Status] and b014 [Dig In Status].
A410...A425 [Preset Freq x].
[Speed Referencex] = 16). See L200...L214
[Jog Accel/Decel].
t081 [Relay Outx Sel] and t069, t072
L180...L187 [Stp Logic x].
t081 [Relay Outx Sel] and t069, t072
L180...L187 [Stp Logic x].
A571
A431
[Opto
[Opto
73
