Chapter 2: Jumpers and Connectors
Locations of the Jumpers and Connectors
The figure below is the 4BV06201C1X10 main board which is the board used in the VTC 6201 system. It shows the locations of the jumpers and connectors.
SATA DOM
AREA
PCI 104 AREA
15
Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved
VTC 6201 Series User Manual
