Chapter 2: Jumpers and Connectors
MCU COM Port
Connector size: 1x3, 2.0mm
Connector location: JP1
1
3
Connector pin definition
Pin
Function Description
1
TX
2
RX
3
GND
Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved
Temp Sensor
Connector size: 1x2, 2.54mm
Connector location: JP5
2
1
Connector pin definition
Pin
Function Description
1
SENSOR+
2
GND
27
VTC 6201 Series User Manual
