Chapter 3: Jumpers and Connectors
Locations of the Jumpers and Connectors
The figure below is the mainboard used in the VMC system. It shows the locations of the jumpers and connectors.
Mainboard
J1
SW1
J2
JP1
J6
JP2
J8
CN3
J9
SW3
SW6
SW7
22
Copyright © 2014 NEXCOM International Co., Ltd. All rights reserved
VMC 100/1100 Series User Manual
