Chapter 2: Jumpers and Connectors
RS485/RS232 COM2 Connector for VTC 6201/VTC 6201-M
Connector location: CN19
1
2
9
10
Connector pin definition
Pin
Definition
1
DCD/TX-/RX- (RS485)
3
TXD
5
GND
7
RTS
9
RI
Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved
Pin
Definition
2
RXD/TX+/RX+(RS485)
4
DTR
6
DSR
8
CTS
19
VTC 6201 Series User Manual
