Chapter 3: System Setup
Installing the PCI-104 Module
1. Locate for the PCI-104 slot on the board.
Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved
2. Position the PCI-104 module above the slot then press it down firmly
until it is completely seated in the slot. This will at the same time align the
module's mounting holes to the mounting studs on the board.
PCI-104 slot
Mounting stud
40
PCI-104 module
Mounting hole
Mounting stud
VTC 6201 Series User Manual
