Chapter 2: Jumpers and Connectors
GAL Programmer Connector
Connector size: 1x6 6-pin header, 2.54 mm
Connector location: JP2
1
6
Connector pin definition
Pin
Definition
1
VCC3_3
2
GND
3
TCK
4
TDO
5
TDI
6
TMS
Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved
MCU Programmer Connector
Connector size: 1x5 5-pin header, 2.54 mm
Connector location: JP3
5
1
Connector pin definition
Pin
Definition
1
+3.3ALW
3
MRST
5
GND
20
Pin
Definition
2
C2D
4
C2CK
VTC 6201 Series User Manual
