Chapter 3: System Setup
4. Now place the SATA drive on the metal bracket then tighten the head
bolt screws to secure the drive on the metal bracket.
Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved
5. Align the head bolt screws with the mounting studs on the main board or
PCI104 Module. Tighten the head bolt screws to secure the drive to the
chassis.
Head bolt screw
Metal bracket
44
Mounting stud
VTC 6201 Series User Manual
Head bolt screw
