Appendix B: VTC 6201/6201-M Main Board

Appendix B: VTC 6201/6201-M Main Board

VTC 6201/6201-M Specifications

Expansion
▪
1 GPS Module
▪
1 PCI-104 socket
▪
1 Bluetooth module (optional)
▪
2 Mini PCI Express socket
- 1 PCIe + USB interface for 3.5G module
▪
USB x 1 for 3.5G module
Storage
▪
One SATA 2.5" HDD bay
▪
One SATA DOM
I/O Interfaces - Front
▪
4 x SMA Antenna holes for WLAN/ HSDPA/ BT
▪
1 power button
▪
1 x System reset button
▪
2 x SIM card socket
▪
2 USB 2.0
▪
5 x LED's for power stand-by (on power button), Power Status, HDD,
WLAN/ HSDPA and GPIO
▪
1 line-out
▪
1 mic-in
Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved
I/O Interfaces - Rear
▪
3 x GigaLAN RJ45 with LED connectors (optional M12 connectors x 2)
▪
9V~60V wide range DC power input, power ignition signal control
(ignition, power & ground)
▪
Dual VGA output (Clone mode)
▪
5V/1A, 12V/1A DC power output, can be controlled by S/W
▪
Audio Mic-In x 1, Line-Out x 1
▪
2 x RS232 (COM1/2)
▪
1 x RS232/RS485 (COM3)
▪
USB 2.0 x 2
▪
1 x SMA antenna hole for GPS
▪
LVDS x 1 (DB26 female connector for LVDS with backlight, control
power (+12V) and USB 2.0 x 1)
▪
GPIO x 1 (4 input & 4 output)
▪
FUSE
