Chapter 2: Jumpers and Connectors
Bluetooth Connector
Connector size: JST 10-pin, 2.54 mm pitch
Connector location: J6
10
1
Connector pin definition
Pin
Definition
1
GND
3
BT_3.3V
5
BT_AUDIO_EN_R
7
NC
9
USB_9P_L
Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved
Pin
Definition
2
NC
4
NC
6
NC
8
USB_9N_L
10
GND
33
VTC 6201 Series User Manual
