Appendix A: I/O Address Function
Status of NEXCOM battery (8 bits)
I/O port : 0EE3H
Bit
Status for G sensor detection
Bit 0
0: Normal
1: Abnormal (X-axis or Y-axis degree is about 90 or -90)
Power mode
Bit 1
0: 24V system
1: 12V system
Fan mode
Bit 2
0: Auto
1: Always on
Status of Smart battery
Bit 3
0: No discharging
1: Discharging
Status of Fan R
Bit 4
0: Well
1: Failed
Status of Fan R
Bit 5
0: Action
1: Inaction
Status of Fan L
Bit 6
0: Well
1: Failed
Status of Fan L
Bit 7
0: Action
1: Inaction
Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved
Function Description
GPIO
I/O port : 0EE4H
Bit
Bit 0-3
Bit 4-7
51
Function Description
GPO 1-4
GPI 1-4
VTC 6201 Series User Manual
