NEXCOM International Co., Ltd.
Mobile Computing Solutions
Vehicle Telematics Computer
VTC 6201 / VTC 6201-M
User Manual
NEXCOM International Co., Ltd.
Published October 2015
www.nexcom.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VTC 6201 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nexcom VTC 6201

Summary of Contents for Nexcom VTC 6201

  • Page 1 NEXCOM International Co., Ltd. Mobile Computing Solutions Vehicle Telematics Computer VTC 6201 / VTC 6201-M User Manual NEXCOM International Co., Ltd. www.nexcom.com Published October 2015...

  • Page 2: Table Of Contents

    Key Features ....................1 GAL Programmer Connector ..............20 Hardware Specifications ................3 MCU Programmer Connector ..............20 Getting to Know VTC 6201 / VTC 6201-M ........... 6 LVDS Connector + USB0 ................21 Front Panel ....................6 VGA Port ....................22 Getting to Know VTC 6201 / VTC 6201-M ...........
  • Page 3 Chapter 3: System Setup ............34 Removing the Chassis Cover ..............34 Installing a GPRS/UMTS/HSDPA Module ............35 Installing a Bluetooth Module..............38 Installing the PCI-104 Module ..............40 Copyright © 2011 NEXCOM International Co., Ltd. All rights reserved VTC 6201 Series User Manual...

  • Page 4: Preface

    VTC 6201 / VTC 6201-M is a trademark of NEXCOM International Co., more of the following measures: Ltd.

  • Page 5: Rohs Compliance

    1,000ppm. of the general public to electromagnetic fields (0–300 GHz). Changes or In order to meet the RoHS compliant directives, NEXCOM has established an modifications to this product not authorized by the manufacturer could void engineering and manufacturing task force in to implement the introduction the EMC compliance and negate your authority to operate the product.

  • Page 6: Warranty And Rma

    Customers must collect all the information about the problems encountered and note anything abnormal or, print out any on-screen ▪ If RMA goods can not be repaired, NEXCOM will return it to the customer messages, and describe the problems on the “NEXCOM RMA Service without any charge.
  • Page 7 Component fee: NEXCOM will only charge for main components, such as SMD chip, BGA chip, etc. Passive components will be repaired for free, ex: resistors, capacitors. If RMA goods can not be repaired, NEXCOM will return it to the customer without any charge. Warnings...

  • Page 8: Safety Information

    Discard used batteries according to the manufacturer’s instructions. viii Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 9: Safety Precautions

    11. All cautions and warnings on the equipment should be noted. 19. The computer is provided with CD drives that comply with the appropriate safety standards including IEC 60825. Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 10: Technical Support And Assistance

    Technical Support and Assistance Conventions Used in this Manual Warning: Information about certain situations, which if not 1. For the most updated information of NEXCOM products, visit NEXCOM’s observed, can cause personal injury. This will prevent injury to website at www.nexcom.com.

  • Page 11: Global Service Contact Information

    ZhongHe District, Beijing, 100094, China New Taipei City, 23586, Taiwan, R.O.C. Tel: +86-010-5704-2680 Tel: +886-2-8226-7796 Fax: +86-010-5704-2681 Fax: +886-2-8226-7792 Email: sales@nexcom.cn Email: sales@nexcom.com.tw www.nexcom.cn www.nexcom.com.tw Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...
  • Page 12 Wuhan, 430070, China Building 11, 599 Yunling Road, Putuo District, Shanghai, 200062, China Tel: +86-27-8722-7400 Tel: +86-21-6125-8282 Fax: +86-27-8722-7400 Fax: +86-21-6125-8281 Email: sales@nexcom.cn Email: frankyang@nexcom.cn www.nexcom.cn www.nexcom.cn Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 13: Package Contents

    Preface Package Contents Before continuing, verify that the VTC 6201 / VTC 6201-M package that you received is complete. Your VTC 6201 / VTC 6201-M package should have all the items listed in the following table. Item Name Specification 4NCPM00302X00 POWER CON 3P PHOENIX CONTACT 5.08mm MALE DIP GREEN...

  • Page 14: Ordering Information

    Preface Ordering Information The following provides ordering information for VTC 6201 / VTC 6201-M. ▪ VTC 6201 (P/N: 10V00620100X0) Intel ® Atom™ D510 1.66GHz processor, 1GB DDR2, GPS module and GPS antenna and in support of three GigaLAN and two sim card slots.

  • Page 15: Chapter 1: Product Introduction

    ▪ Low battery power protection setting by software e13 Mark certification ▪ ▪ External smart battery back-up Built-in U-blox M8N GPS, optional Dead Reckoning support Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...
  • Page 16 Chapter 1: Product Introduction The VTC 6201 / VTC 6201-M is an innovative in-vehicle computer for use in any car, truck, or even for maritime applications. The design itself makes the system available as a complete system allowing the user to easily define and build requirements.

  • Page 17: Hardware Specifications

    Supports S3/S4 suspend mode ▪ 1 x system reset button ▪ 1 x Mic-In, 1 x Line-Out ▪ 4 x mounting holes SMA-type for HSDPA/BT Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 18: Power Management

    Storage: MIL-STD-810F, Method 514.5, Category 24, Integrity Test ▪ If the ignition is off and the system is still on after 3 minutes, VTC 6201 / • Shock (with SSD) VTC 6201-M will shut down automatically. - Operating: MIL-STD-810F, Method 516.5, Procedure I, Trucks and ▪...
  • Page 19 ▪ If the ignition is turned off again and power-on delay is in progress, VTC 6201 / VTC 6201-M will cancel the delay and stay in power-off status. ▪ If the ignition is turned off again and the power-on delay ended (in BIOS process), VTC 6201 / VTC 6201-M will shut down immediately.

  • Page 20: Getting To Know Vtc 6201 / Vtc 6201-M

    Use the BIOS to select the start up and shut down voltages. When the ignition is from “high” to “low”, VTC 6201 / VTC 6201-M will 2. Mode B. When the input power voltage is 24V, use SW2 to select this turn off automatically.
  • Page 21 SIM Card Socket Line-out VTC 6201 / VTC 6201-M can be internally integrated with a 3.5G Mini Card module. The SIM card bracket is on the board. When using the GPRS/UMTS/ Line-out is a stereo output for connecting external speakers.

  • Page 22: Getting To Know Vtc 6201 / Vtc 6201-M

    Line-out COM1 LAN3 LAN1 COM2 LVDS GPIO 9V-60V IGNITION ** Use power cable (+) with fuse for system protection LAN2 DC IN 9V-60V Mic-in 5V/12V/SMBUS Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...
  • Page 23 I/O Port address IRQ number Number the Rear panel COM1 3F8H IRQ4 COM1 COM2 2F8H IRQ3 COM2 COM3 3E8H IRQ5 COM3 COM6 238H IRQ10 GPS module Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...
  • Page 24 +5 VDC (0.5A) and +12VDC (0.5A) power output and SMBus LCDD05(OUT2) Power on push button (w/ VTK 33M-01 connection) LCDD04(OUT2#) Panel_backlight LCDD_GND Panel-Gnd USB_0# Contact_DET# USB_0 USB_VCC Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...
  • Page 25 Audio Jacks (MIC-IN and LINE-OUT) ▪ MIC-IN jack receives monophonic input from an external microphone. ▪ LINE-OUT jack is the stereo output for connecting external speakers. Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...
  • Page 26 Chapter 1: Product Introduction VTC 6201/VTC 6201-M 260.0 Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 27: Chapter 2: Jumpers And Connectors

    This chapter describes how to set the jumpers on the motherboard. Note dry environments. A grounding strap is warranted whenever danger of static electricity exists. that the following procedures are generic for all VTC 6201/ 6201-M. Before You Begin Precautions ▪...

  • Page 28: Jumper

    (on) and open (off). Two-Pin Jumpers: Open (Left) and Short (Right) Three-Pin Jumpers: Pins 1 and 2 Are Short Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 29: Locations Of The Jumpers And Connectors

    Chapter 2: Jumpers and Connectors Locations of the Jumpers and Connectors The figure below is the 4BV06201C1X10 main board which is the board used in the VTC 6201 system. It shows the locations of the jumpers and connectors. SATA DOM...
  • Page 30 Chapter 2: Jumpers and Connectors The figure below is the 4BV06201C1X10 main board which is the board used in the VTC 6201-M system. It shows the locations of the jumpers and connectors. SATA DOM AREA PCI 104 AREA Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved...

  • Page 31: Jumper Settings

    CMOS Input Voltage Select (J4) Status Function Description 1-2 (default) Short (default) VBAT IN Short Clear CMOS MCU COM Port (JP1) Temp Sensor (JP5) Function Description Function Description SENSOR+ Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 32: Connectors

    Description DCD (RS232) RXD (RS232) GIN1 GIN2 TXD (RS232) DTR (RS232) GIN3 GIN4 DSR (RS232) GOUT4 GOUT1 RTS (RS232) CTS (RS232) GOUT2 GOUT3 RI (RS232) Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 33: Rs485/Rs232 Com2 Connector For Vtc 6201/Vtc 6201-M

    Chapter 2: Jumpers and Connectors RS485/RS232 COM2 Connector for VTC 6201/VTC 6201-M Connector location: CN19 Connector pin definition Definition Definition DCD/TX-/RX- (RS485) RXD/TX+/RX+(RS485) Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 34: Gal Programmer Connector

    Connector size: 1x5 5-pin header, 2.54 mm Connector location: JP2 Connector location: JP3 Connector pin definition Connector pin definition Definition Definition Definition VCC3_3 +3.3ALW MRST C2CK Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 35: Lvds Connector + Usb0

    LVDS_9(OUT3) LVDS_0(OUT0#) LVDS_GND Power on push buttom LVDS_8(OUT3#) Panel_VDD USB_4# USB_GND USB_4 USB_VCC (+5V) LVDS_GND LVDS_GND USB_GND USB_GND LVDS_7(CLK) LVDS_3(OUT1) LVDS_6(CLK#) LVDS_2(OUT1#) Panel_backlight(12V) LVDS_GND LVDS_GND Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 36: Vga Port

    Connector pin definition Definition Definition Definition Definition GREEN BLUE N/C1 N/C2 N/C3 N/C4 LAN Speed LED VCC3_3 DDCDAT LAN Link LED VCC3_3 Hsync Vsync DDCCLK Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 37: Usb Ports

    Connector location: USB1 and USB2 Connector location: J2 Connector pin definition Connector pin definition Definition Definition Definition Definition Panel_backlight Panel_VDD DATA1- DATA1+ LVDS_PANEL LVDS_BIASON DATA- DATA+ Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 38: External 12V & 5V Power And Smbus Connector

    Connector location: CN1 Connector size: 6-pin jack, 25.9x12.6x17.0mm Connector location: CN18 Connector pin definition Connector pin definition Definition Definition Definition Definition MIC_JD SMBCLK MIC_OUT SMBDATA Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 39: Line-Out Jacks

    Connector location: CN16 Connector pin definition Connector pin definition Pin No. Status Function Description Definition Definition LINE_OUT_L SURR_JD 1-3, 2-4 (default) Short +3.3V LINE_OUT_R 3-5, 4-6 Short Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 40: Connector

    Chapter 2: Jumpers and Connectors PCI-104 Connector Power Button Connector location: CN21 Connector location: SW1 Reset Button Connector location: SW2 Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 41: Mcu Com Port

    Connector size: 1x3, 2.0mm Connector size: 1x2, 2.54mm Connector location: JP1 Connector location: JP5 Connector pin definition Connector pin definition Function Description Function Description SENSOR+ Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 42: Power Input

    Connector location: LED1 Connector location: CON1 Connector pin definition Connector pin definition Function Description Pin No. Function Description POWER LED HD LED VIN 9V-60V IGNITION Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 43: Gpio And Umts Leds

    LED I/O Port Address and Data Connector pin definition Function Description Definition I/O PORT Address: 0EE0; Bit0: 1 (Light), 0 (Dark) UMTS STATUS SATA_TXP0 - SATA_TXN0 SATA_RXN0 SATA_RXP0 Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 44: Sata Power Connector

    Connector size: 1x2 2-pin boxed header, 2.5 mm JST Connector location: J5 Connector location: J10 Connector pin definition Connector pin definition Definition Definition VCC5 VCC5 Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 45: Mini-Pcie Slot (3.5G)

    REFCLK- USB_D+ VCC_ USIM CLK USB_D+ MSM26_DIG REFCLK+ USIM RST +V3.3S LED_WWAN# +V3.3S LED_WWAN# LED_WLAN# DISABLE# LED_WPAN# W_DISABLE# PERST# +V1.5S PERn0 +3.3S PERp0 +V3.3S +V3.3S Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 46: Gps Connector

    Connector pin definition Connector Pin Definition Definition Definition Definition GPS_BAT POWER VOLTAGE RESET SIGNAL GPS_LED# CLOCK SIGNAL SP_TX1 VPP:PROGRAM VOLTAGE SP_RX1 Contact present switch VCC3_3S Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 47: Bluetooth Connector

    Chapter 2: Jumpers and Connectors Bluetooth Connector Connector size: JST 10-pin, 2.54 mm pitch Connector location: J6 Connector pin definition Definition Definition BT_3.3V BT_AUDIO_EN_R USB_9N_L USB_9P_L Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 48: Chapter 3: System Setup

    2. Lift the cover upward then remove it from the chassis. Remove these screws and put them in a safe place for later use. Front View VTC 6201 Rear View VTC 6201-M Rear View Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 49: Installing A Gprs/Umts/Hsdpa Module

    GPRS/UMTS/ HSDPA module Mini PCI Mini PCI Express slot Express slot Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...
  • Page 50 3. Push the module down then secure it with mounting screws. 4. Attach one end of the RF cable onto the module. Attach RF cable to the module Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...
  • Page 51 6. Mount the other end of the cable to the antenna mounting hole located the module. at the front panel of the chassis. RF cable mounted at the front panel Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 52: Installing A Bluetooth Module

    1. The USB header shown below is used to install a Bluetooth module. 2. Install the provided mounting stud as shown in the illustration below. Mounting stud USB header Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...
  • Page 53 5. Mount the other end of the cable to the Bluetooth mounting hole located Bluetooth at the front panel of the chassis. module Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 54: Installing The Pci-104 Module

    This will at the same time align the module’s mounting holes to the mounting studs on the board. PCI-104 slot Mounting hole Mounting stud Mounting stud PCI-104 module Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...
  • Page 55 Chapter 3: System Setup 3. Secure the module with mounting screws. Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 56: Installing Sata Hard Drive

    If you intend to install a Mini PCI Express module or a bluetooth module, please install these devices first before proceeding to the next step. Refer to their respective sections in this chapter for instructions on installing a Mini PCI Express module or a bluetooth module. Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...
  • Page 57 Chapter 3: System Setup 3. Tighten the mounting screws to secure the HDD brackets in place. HDD bracket HDD bracket HDD bracket HDD bracket Top View Bottom View Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...
  • Page 58 PCI104 Module. Tighten the head bolt screws to secure the drive to the chassis. Head bolt screw Metal bracket Mounting stud Head bolt screw Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...
  • Page 59 SATA drive. Power connector SATA data cable SATA connector Cable connected to Cable connected the SATA connector to the SATA drive on the board Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...
  • Page 60 SATA drive. SATA power cable Cable connected to the SATA power connector Cable connected on the board to the SATA drive Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 61: Installing The Sodimm

    The gold-plated connector on the edge of the module will almost correctly locked into position. completely disappear inside the socket. Clip SODIMM SODIMM socket Clip Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 62: Removing The Fuse

    1. Remove the screw of the fuse panel and then remove the panel. 2. Use nose pliers to remove the fuse. Screw Fuse Fuse panel Nose pliers Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 63: Rackmount Brackets

    Secure the bracket to the system Rackmount bracket Fasten screws to mount the system to the wall Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 64: Appendix A: I/O Address Function

    Bit7 Bit 3 0: Vehicle Battery is Low Voltage Description 8 bits data (Bit 7 is highest bit of data) 1: Vehicle Battery is OK Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...
  • Page 65 Bit 5 0: Action 1: Inaction Status of Fan L Bit 6 0: Well 1: Failed Status of Fan L Bit 7 0: Action 1: Inaction Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...
  • Page 66 Time (sec) 1: Enable (default) 1 (default) External +5V power Bit 3 0: Disable 1: Enable (default) Auto clear WDT timer when reading/writing I/O port 0EE5H. Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 67: Appendix B: Vtc 6201/6201-M Main Board

    2 USB 2.0 ▪ 5 x LED’s for power stand-by (on power button), Power Status, HDD, WLAN/ HSDPA and GPIO ▪ 1 line-out ▪ 1 mic-in Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 68: Appendix C: Vehicle Power Management Setup

    Appendix C: Vehicle Power Management Setup Appendix C: Vehicle Power Management Setup External Power Output Setting External +12V and +5V Turn On Simultaneously External +12V and +5V Turn Off Simultaneously Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...
  • Page 69 Appendix C: Vehicle Power Management Setup External +12V Turn On Only External +5V Turn On Only Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 70: Startup And Shutdown Voltage Setting

    12.5V and the shutdown voltage to 11.5V. If the input voltage setting is 12V : set the startup voltage to 12.5V and the shutdown voltage to 11V. Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...
  • Page 71 25V and the shutdown voltage to 22V. If the input voltage setting is 24V : set the startup voltage to 25V and the shutdown voltage to 23V. Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...
  • Page 72 50V and the shutdown voltage to 46V. If the input voltage setting is 48V : set the startup voltage to 50V and the shutdown voltage to 48V. Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...
  • Page 73 Appendix C: Vehicle Power Management Setup If the input voltage setting is 9V~60V ignore the startup/shutdown setting. Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 74: Power-On Delay Setting

    Appendix C: Vehicle Power Management Setup Power-on Delay Setting Disable Power-on Delay Enable Power-on Delay Delay time can be set at 10sec/30sec/1min./5min./10min./15min./30min./ 1hour. Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...
  • Page 75 Appendix C: Vehicle Power Management Setup Disable Power-off Delay Enable Power-off Delay Delay time can be set at 20sec/1min./5min./10min./30min./1hour/6hour/ 18hour. Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...

  • Page 76: Appendix D: Power Consumption

    OS: XP English Burn-in Software: Version 5.0 Idle Mode 100% Burn-in Mode 1.55A / 12V 1.81A / 12V 0.28A/12V 0.01A /12V 0.01A /12V * Device: N/A Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved VTC 6201 Series User Manual...
