Appendix A: I/O Address Function
WDT
I/O port : 0EE5H
Bit
WDT Disable/Enable
Bit 3
0: Disable (default)
1: Enable
Bit 2, 1, 0: Time Setting
Bit 2~0
000
001
010
011
100
101
110
111
Auto clear WDT timer when reading/writing I/O port 0EE5H.
Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved
Function Description
Time (sec)
1 (default)
2
4
8
16
32
64
128
Onboard Module Disable/Enable
I/O port : 0EE6H
Bit
3.5G module
Bit 0
0: Disable
1: Enable (default)
WLAN module
Bit 1
0: Disable
1: Enable (default)
External +12V power
Bit 2
0: Disable
1: Enable (default)
External +5V power
Bit 3
0: Disable
1: Enable (default)
52
Function Description
VTC 6201 Series User Manual
