IMPORTANT!
Ensure the Page Scaling setting
is set to NONE when printing this
page. Verify dimensions of printed
template are accurate before
cutting panel.
NOTES:
1.
DIMENSIONS: INCHES[mm]. METRIC VALUES ARE FOR REFERENCE ONLY.
2.
DIMENSIONS ARE NOMINAL AND TOLERANCES ARE NOT IMPLIED UNLESS
SPECIFICALLY STATED.
190-01115-01
Rev. AA
Figure 11-5 GMC 305 Panel Cutout Template
G3X/G3X Touch Installation Manual - GMC 305 Installation
GMC 305 PANEL CUTOUT
CUT OUT PANEL
TO INSIDE LINE
Page 11-6
