VLT HVAC Drive Operating Instructions

6-16 Terminal 53 Filter Time Constant

Range:
*
0.001s [0.001 - 10.000 s]

6-17 Terminal 53 Live Zero

Option:
[0] Disabled
*
Enabled
[1]

6-20 Terminal 54 Low Voltage

Range:
*
0.07V [0.00 – par. 6-21]

6-21 Terminal 54 High Voltage

Range:
*
10.0V [Par. 6-20 to 10.0 V]
6-24 Terminal 54 Low Ref./Feedb. Value
Range:
*
0.000 Unit [-1000000.000 to par.
6-25]
6-25 Terminal 54 high ref./feedb. value
Range:
*
100.000 Unit [Par. 6-24 to
1000000.000]
6-26 Terminal 54 Filter Time Constant
Range:
*
0.001s [0.001 - 10.000 s]
6-27 Terminal 54 Live Zero
Option:
[0] Disabled
* Enabled
[1]
6-50 Terminal 42 Output
Select the function of Terminal 42 as an analog current output.
[0] No operation
*
Output frequency
[100]
Function:
Enter the time constant. This is a first-order digital low pass filter time constant for suppressing electrical noise
in terminal 53. A high time constant value improves dampening but also increases the time delay through the
filter.
This parameter cannot be adjusted while the motor is running.
Function:
This parameter makes it possible to disable the Live Zero monitoring. E.g. to be used if the analog outputs are
used as part of a decentral I/O system (e.g. when not part of any frequency converter related control functions,
but feeding a Building Management system with data)
Function:
Enter the low voltage value. This analog input scaling value should correspond to the low reference/feedback
value, set in par. 6-24.
Function:
Enter the high voltage value. This analog input scaling value should correspond to the high reference/feedback
value set in par. 6-25.
Function:
Enter the analog input scaling value that corresponds to the low voltage/low current value set in par. 6-20/6-22.
Function:
Enter the analog input scaling value that corresponds to the high voltage/high current value set in par. 6-21/6-23.
Function:
Enter the time constant. This is a first-order digital low pass filter time constant for suppressing electrical noise
in terminal 54. A high time constant value improves dampening but also increases the time delay through the
filter.
This parameter cannot be adjusted while the motor is running.
Function:
This parameter makes it possible to disable the Live Zero monitoring. E.g. to be used if the analog outputs are
used as part of a decentral I/O system (e.g. when not part of any frequency converter related control functions,
but feeding a Building Management System with data)
MG.11.A6.02 - VLT ® is a registered Danfoss trademark
6. How to programme the frequency converter
6
91
