4-10 Motor Speed Direction

Selects the motor speed direction required.
Use this parameter to prevent unwanted reversing. When
4-10 is internally set to Clockwise [0] only.
[0]
Clockwise
*
Both directions
[2]
NB!
The setting in par.4-10 has impact on the Flying Start in par.1-73.

4-53 Warning Speed High

Range:
*
par. 4-13 RPM
[Par. 4-52 - par.
4-13 RPM]
NB!
Any changes in par. 4-13, Motor Speed High Limit [RPM] will reset the value in par. 4-53 to the same value as set in par. 4-13.
If a different value is needed in par. 4-53, it must be set after programming of par. 4-13!

4-56 Warning Feedback Low

Option:
[-999999.999
-999999.999
*
999999.999
]

4-57 Warning Feedback High

Range:
*
999999.999
[Par. 4-56 -
999999.999]
4-64 Semi-Auto By-pass Feature
Option:
*
Off
[0]
[1]
Enabled
5-01 Terminal 27 Mode
Option:
*
Input
[0]
[1]
Output
Only operation in clockwise direction will be allowed.
Operation in both clockwise and anti-clockwise direction will be allowed.
Function:
Enter the n
value. When the motor speed exceeds this limit (n
HIGH
outputs can be programmed to produce a status signal on terminal 27 or 29 and on relay output 01 or 02.
Programme the upper signal limit of the motor speed, n
converter. Refer to the drawing in this section.
Function:
-
Enter the lower feedback limit. When the feedback falls below this limit, the display reads Feedb Low. The signal
outputs can be programmed to produce a status signal on terminal 27 or 29 and on relay output 01 or 02.
Function:
Enter the upper feedback limit. When the feedback exceeds this limit, the display reads Feedb High. The signal
outputs can be programmed to produce a status signal on terminal 27 or 29 (FC 302 only) and on relay output
01 or 02 (FC 302 only).
Function:
No function
Starts the Semi-Automatic Bypass set-up and continue with the procedure described above.
Function:
Defines terminal 27 as a digital input.
Defines terminal 27 as a digital output.
MG.11.A6.02 - VLT
®
is a registered Danfoss trademark
6. How to programme the frequency converter
par. 1-00 Configuration Mode
), the display reads SPEED HIGH. The signal
HIGH
, within the normal working range of the frequency
HIGH
is set to Closed Loop [3], par.
6
85
