6. How to programme the frequency converter
Q3-30 Single Zone Int. Set Point
1-00 Configuration Mode
20-12 Reference / Feedback Unit
3-02 Minimum Reference
3-03 Maximum Reference
6-22 Terminal 54 Low Current
6-24 Terminal 54 Low ref/feedb Value
6-25 Terminal 54 High ref/feedb Value
6-26 Terminal 54 Filter Time Constant
6-27 Terminal 54 Live Zero
6-00 Live zero Timeout Time
6-01 Live zero Timeout Function
20-21 Setpoint 1
20-81 PID Normal / Inverse Control
20-82 PID Start Speed [RPM]
20-83 PID Start Speed [Hz]
20-93 PID Proportional Gain
20-94 PID Integral Time
6
72
Q3-3 Closed Loop Settings
Q3-31 Single Zone Ext. Set Point
1-00 Configuration Mode
20-12 Reference / Feedback Unit
3-02 Minimum Reference
3-03 Maximum Reference
6-10 Terminal 53 Low voltage
6-11 Terminal 53 High voltage
6-12 Terminal 53 Low Current
6-13 Terminal 53 High Current
6-14 Terminal 53 Low ref/feedb. Value
6-15 Terminal 53 High ref/feedb. Value
6-22 Terminal 54 Low Current
6-24 Terminal 54 Low ref/feedb Value
6-25 Terminal 54 High ref/feedb Value
6-26 Terminal 54 Filter Time Constant
6-27 Terminal 54 Live Zero
6-00 Live zero Timeout Time
6-01 Live Zero Timeout Function
20-81 PID Normal / Inverse Control
20-82 PID Start Speed [RPM]
20-83 PID Start Speed [Hz]
20-93 PID Proportional Gain
20-94 PID Integral Time
MG.11.A6.02 - VLT ® is a registered Danfoss trademark
®
VLT HVAC Drive Operating Instructions
Q3-32 Multi Zone / Adv
1-00 Configuration Mode
20-12 Reference / Feedback Unit
3-02 Minimum Reference
3-03 Maximum Reference
3-15 Reference 1 Source
3-16 Reference 2 Source
20-00 Feedback 1 Source
20-01 Feedback 1 Conversion
20-02 Feedback 1 Source Unit
20-03 Feedback 2 Source
20-04 Feedback 2 Conversion
20-05 Feedback 2 Source Unit
20-06 Feedback 3 Source
20-07 Feedback 3 Conversion
20-08 Feedback 3 Source Unit
6-10 Terminal 53 Low Voltage
6-11 Terminal 53 High Voltage
6-12 Terminal 53 Low Current
6-13 Terminal 53 High Current
6-14 Terminal 53 Low ref/feedb. Value
6-15 Terminal 53 High ref/feedb. Value
6-16 Terminal 53 Filter Time
6-17 Terminal 53 Live Zero
6-20 Terminal 53 Low Voltage
6-21 Terminal 53 High Voltage
6-22 Terminal 53 Low Current
6-23 Terminal 53 High Current
6-24 Terminal 53 Low ref/feedb.
6-25 Terminal 53 High ref/feedb. Value
6-26 Terminal 53 Filter Time
6-27 Terminal 53 Live Zero
6-00 Live zero Timeout Time
6-01 Live zero Timeout Function
4-56 Warning Feedback Low
4-57 Warning Feedback High
20-20 Feedback Function
20-21 Setpoint 1
20-22 Setpoint 2
20-81 PID Normal / Inverse Control
20-82 PID Start Speed [RPM]
20-83 PID Start Speed [Hz]
20-93 PID Proportional Gain
20-94 PID Integral Time
