VLT HVAC Drive Operating Instructions

5-11 Terminal 19 Digital Input

Option:
*
No operation
[0]

5-12 Terminal 27 Digital Input

Option:
*
Coast Inverse
[2]

5-13 Terminal 29 Digital Input

Option:
*
Jog
[14]

5-14 Terminal 32 Digital Input

Option:
*
No Operation
[0]
5-15 Terminal 33 Digital Input
Option:
*
No Operation
[0]
5-40 Function Relay
Select options to define the function of the relays.
The selection of each mechanical relay is realised in an array parameter.
Array [8]
[0] No Operation
[1] Control Ready
[2] Drive Ready
[3] Drive Ready/Remote
[4] Stand-by/No Warning
*
Running (＊Relay 2)
[5]
[6] Running/No Warning
[8] Run on Ref./No Warn-
ing
*
Alarm (＊Relay 1)
[9]
[10] Alarm or Warning
[11] At Torque Limit
[12] Out of Current Range
[13] Below Current, low
[14] Above Current, high
[15] Out of Speed Range
[16] Below Speed, low
[17] Above Speed, high
[18] Out of Feedb. Range
Function:
Same options and functions as par. 5-1*
Function:
Same options and functions as par. 5-1*
Function:
Same options and functions as par. 5-1*
Function:
Same options and functions as par. 5-1*
Function:
Same options and functions as par. 5-1*
Option MCB 105: Relay 7 [6], Relay 8 [7] and Relay 9 [8])
MG.11.A6.02 - VLT ® is a registered Danfoss trademark
6. How to programme the frequency converter
Digital Inputs Pulse input
, except for
Digital Inputs Pulse input
, except for
Digital Inputs
.
Digital Inputs Pulse input
, except for
Digital Inputs
.
(Relay 1 [0], Relay 2 [1]
.
.
.
