GETTING STARTED

3.
The easiest way to get the speedMOPSlcdCE board running is to use a starter kit from
Kontron Embedded Modules GmbH. Take the following steps:
1. Turn off the power supply (part of the starter kit).
2. Connect the power supply to the starter kit baseboard (part of the starter kit).
3. Plug a suitable SDRAM memory module into the SODIMM socket of the speedMOPS.
4. Plug the speedMOPS to the PC/104 and PC/104Plus bus connectors on the starter kit
baseboard.
5. Make all necessary connections from the speedMOPS to the starter kit board. (the cables come
with the starter kit). The starter kit board offers various interfaces on standard connectors.
6. Connect the CRT monitor to the CRT interface or a LCD panel to the JILI interface by using the
corresponding adapter cable.
7. Plug a keyboard to the starter kit's keyboard connector.
8. Connect the floppy drive (part of the starter kit) with the data cable (part of the starter kit) to
the speedMOPS floppy interface.
9. Connect the power supply to the floppy's power connector.
10. Plug a hard-drive data cable to the speedMOPS hard-disk interface. Attach the hard disk to the
connector at the opposite end of the cable.
11. If necessary, connect the power supply to the hard disk's power connector.
12. Make sure all your connections have been made correctly.
13. Turn on the power.
14. Enter the BIOS by pressing the F2 key during boot-up. Make all changes in the BIOS setup. See
the BIOS chapter of this manual for details.
