External Battery
19.5
You can connect an external battery to Pin 3 (BATT) of the power connector instead of Pin 9 of the
keyboard connector. For more information refer to the Keyboard and Feature Interface section.
Note: The two battery inputs are protected against each other by diodes.
Power Interface
46
KONTRON
speedMOPSlcdCE User's Guide
