- Page 1 COMe Reference Carrier Type 6 Document Revision 1.0 If it‟s embedded, it‟s Kontron.
-
Page 2: Table Of Contents
Connectors and Features ..............14 Power Supply ........................14 5.1.1 ATX Connector and Behavior Control ..................14 5.1.2 Power- and Resetbutton ......................15 5.1.3 LID# and SLEEP# Header ......................16 COM Express® Connector ......................17 Status LEDs .......................... 18 www.kontron.com... - Page 3 High Definition Audio ......................22 Ethernet ..........................24 USB ............................ 25 5.10 Mini PCI express ........................26 5.11 SIM Card..........................27 5.12 Kontron Feature Connector ..................... 28 5.13 DVI-I, HDMI and Displayport ....................29 5.14 Serial Interface ........................30 5.15 FAN ............................ 31 5.16 SMART Battery ........................
-
Page 4: User Information
“as-is” and is subject to change without notice. For the circuits, descriptions and tables indicated, Kontron assumes no responsibility as far as patents or other rights of third parties are concerned. -
Page 5: Warranty
This Kontron Embedded Modules GmbH product is warranted against defects in material and workmanship for the warranty period from the date of shipment. During the warranty period, Kontron Embedded Modules GmbH will at its discretion decide to repair or replace defective products. -
Page 6: Introduction
COMe Reference Carrier Type 6 / Introduction Introduction The COMe Reference Carrier Type 6 for Type 6 modules is designed to allow embedded application developers to get up and running quickly on the COM Express® basic platform, giving them a head start on the total system design. Simply select a Type 6 CPU module, then Plug &... -
Page 7: Specification
COMe Reference Carrier Type 6 / Specification Specification Functional Specification » COM Express® COM.0 Rev 2.0 baseboard compatible to Type 6 pin-out based modules » ATX supply / single supply use » DVI/CRT on DVI-I » Display Port (++) connector »... -
Page 8: Block Diagram
COMe Reference Carrier Type 6 / Specification Block Diagram... -
Page 9: Mechanical Specification
COMe Reference Carrier Type 6 / Specification Mechanical Specification » Size: mini ITX (170mm x 170mm) » max height on top: 36 mm (rear panel audio connector) -
Page 10: Electrical Specification
COMe Reference Carrier Type 6 / Specification Electrical Specification Supply Voltage 8,5V – 18V Power Supply Rise time » The input voltages shall rise from ≤10% of nominal to within the regulation ranges within 0.1ms to 20ms. » There must be a smooth and continuous ramp of each DC input voltage from 10% to 90% of its final set-point following the ATX specification Supply Voltage Ripple »... - Page 11 COMe Reference Carrier Type 6 / Specification environment. Higher temperatures and other environmental stresses (extreme altitude, vibration, salt water exposure, etc.) lower MTBF values. System MTBF: tbd hours »...
-
Page 12: Connector Layout
COMe Reference Carrier Type 6 / Connector Layout Connector Layout Rear Panel The rear panel layout is based on an Intel miniITX mainboard, DH67CF. Therefore the I/O shield for DH67CF can be used for the COMe Ref. Carrier T6. The I/O shield can be directly ordered from Intel‟s spare parts store. -
Page 13: Connector Locations
COMe Reference Carrier Type 6 / Connector Layout Connector Locations... - Page 14 COMe Reference Carrier Type 6 / Connector Layout...
-
Page 15: Component Overview
Status LED: Vin > 18.0V D205 Status LED: POWER COM Express® Connector Row C and D SATA 0 SATA 1 Kontron Feature Connector Connector for external Reset Button External HDD activity LED JUMPER for ATX behavior SATA 2 Front Panel HDAudio connector... - Page 16 COMe Reference Carrier Type 6 / Connector Layout Jumper for disabling optical HD Audio SPDIF SPI flash Connector Jumper for BIOS _DIS1# Ethernet / dual USB connector Jumper for ATX / single supply mode Jumper for Wireless Disable at mini PCI Express COM Express®...
-
Page 17: Connectors And Features
COMe Reference Carrier Type 6 / Connectors and Features Connectors and Features Power Supply 5.1.1 ATX Connector and Behavior Control The COM Express® Reference Carrier Type 6 power supply follows the ATX 2.x specification and the baseboard should be supplied by connecting an ATX PSU with 20pin ATX (J58) and 8pin ATX_12V (J59) supply cable in correct orientation. -
Page 18: Power- And Resetbutton
COMe Reference Carrier Type 6 / Connectors and Features 5.1.2 Power- and Resetbutton The COM Express® Reference Carrier Type 6 provides an onboard Reset Button (SW1) and Power Button (SW2). To connect a front panel button from your chassis use J40 (Power) or J42 (Reset). Connector Function Reset Button... -
Page 19: Lid# And Sleep# Header
COMe Reference Carrier Type 6 / Connectors and Features 5.1.3 LID# and SLEEP# Header The specification update for PICMG COM.0 modules to revision 2.0 implements new signals for LID and Sleep. The low active signals can be simulated by J89 similar to notebook functionality of closing the lid or pressing the sleep button. -
Page 20: Com Express® Connector
COMe Reference Carrier Type 6 / Connectors and Features COM Express® Connector The COM Express® Reference Carrier Type 6 is a carrier board for Type 6 based COM Express® Computer-on-Modules. They are based on two connectors with 2 rows with 440 pins overall. Please refer to your module documentation for detailed pin-out descriptions. -
Page 21: Status Leds
COMe Reference Carrier Type 6 / Connectors and Features Status LEDs The onboard main status and voltage LED D182-D191 indicates the current power state of the module and if all voltages are working correctly. Some additional status LED shows active or inactive slots and signals. See table below for detailed information. -
Page 22: Serial Ata
COMe Reference Carrier Type 6 / Connectors and Features Serial ATA The COM Express® Type 6 pin-out specification according to COM.0 specification revision 2.0 defines 4 SATA ports. The COM Express® Reference Carrier Type 6 provides 3 7-pin SATA data connectors as standard 1.27mm Pitch Serial ATA High Speed Header with Locking Latch. -
Page 23: Esata
COMe Reference Carrier Type 6 / Connectors and Features eSATA COM Express® Reference Carrier Type 6 provides one port for external SATA on the rear panel. J116 offers 2 USB 2.0 ports and one additional eSATA port. With standard SATA interfacing from the module you can provide cable length up to 1.0 m. -
Page 24: Gpio
COMe Reference Carrier Type 6 / Connectors and Features GPIO The COM Express® Reference Carrier Type 6 provides 4 GPI and 4 GPO signals according to the COM Express® specification. GPIO J48 PIN Description GPIO J48 Pin Description VCC 3.3V GPO0 GPI0 GPO1... -
Page 25: High Definition Audio
Note1: In addition to the default speaker settings, the analog audio Jacks can be reconfigured to perform different functions via the Realtek HDAudio Driver Software which is available on Kontron website. Only microphones still must be connected to the default pink jack. - Page 26 COMe Reference Carrier Type 6 / Connectors and Features Front Panel Audio Connector J43 The front panel audio connector J43 allows connecting a chassis front panel audio with analog microphone input and stereo speaker output. Please use a HAD Description MIC2-L MIC2-R (MIC Power) PRESENCE#...
-
Page 27: Ethernet
COMe Reference Carrier Type 6 / Connectors and Features Ethernet The COM Express® Reference Carrier Type 6 provides a RJ45/Dual USB Combo with a single RJ45 in combination with 2 USB ports (3.0) (USB 0/1). Ethernet Connector J83 with integrated magnetics and LED is configured to support modules with Gigabit Ethernet controller only. -
Page 28: Usb
COMe Reference Carrier Type 6 / Connectors and Features The COM Express® module's USB ports 0 to 1 are available on rear panel connector J83 together with Ethernet. They provide USB 3.0 function, when the module is able to support USB 3.0. USB port 4 and 5 is available on rear panel connector J116 together with eSATA and USB port 6 andn 7 on connector J115 together with Displayport. -
Page 29: Mini Pci Express
COMe Reference Carrier Type 6 / Connectors and Features 5.10 Mini PCI express The COMe Reference Carrier Type 6 provides a full functional miniPCIexpress card socket in full size. All signals are equipped: USB, PCIe and the UIM signals are connected to the SIM card socket. MiniPCIe J90 - Pin Function MiniPCIe J90 - Pin... -
Page 30: Sim Card
COMe Reference Carrier Type 6 / Connectors and Features 5.11 SIM Card The COMe Reference Carrier Type 6 provides a SIM Card connector to use radio based services on miniPCIexpress connector J90. -
Page 31: Kontron Feature Connector
COMe Reference Carrier Type 6 / Connectors and Features 5.12 Kontron Feature Connector The Kontron Feature connector provides additional interfaces such as I2C, SMBus or Power Control Signals. See the table below for detailed pin-out description. Signal Level Signal Description... -
Page 32: Dvi-I, Hdmi And Displayport
COMe Reference Carrier Type 6 / Connectors and Features 5.13 DVI-I, HDMI and Displayport On COMe Reference Carrier Type 6 all three DDI interfaces are available: Usage Connector DDI1 J117 DDI2 Displayport J115 DDI3 HDMI J118 J117 additionally offers VGA signals via the analog pins on the DVI-I connector. To use this on standard analog monitors an adapter form DVI-I to VGA is necessary which is available through usual computer equipment suppliers. -
Page 33: Serial Interface
COMe Reference Carrier Type 6 at connector J109 and J102. J109 and J102 allow SER0 and SER1 as 2-pin RS232 interface COMA with Kontron Adapter cable KAB-DSUB9-2. Please check the documentation of your module if this interface is supported and how to configure. -
Page 34: Fan
COMe Reference Carrier Type 6 / Connectors and Features 5.15 FAN The COMe Reference Carrier Type 6 privides one 4-pin PWM FAN connector directly controlled by the module FAN output specified in the COM.0 revision 2.0 specification if supported by the module. +12V Sense Control (PWM) -
Page 35: Smart Battery
COMe Reference Carrier Type 6 / Connectors and Features 5.16 SMART Battery 5.16.1 Introduction The Core of the SBS is the dual Smart Battery System Manager LTC1760. On COMe Reference Carrier Type 6 both battery connections are provided. Smart Battery Systems have the ability to communicate with the application. Therefore the user gets information about the current state of the battery. -
Page 36: Smart Battery Connector
COMe Reference Carrier Type 6 / Connectors and Features The LTC1760 automatically switches between power sources in less than 10μs to prevent power interruption upon battery or wall adapter removal. It implements all elements of a version 1.1 “Smart Battery System Manager” except for the generation of composite battery information. -
Page 37: Battery Information
COMe Reference Carrier Type 6 / Battery Information Battery Information English: CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer‟s instructions. - Page 38 English, German, French, Danish, Finish and Spanish language. If the battery of this product however is accessible by the end user, it is in the responsibility of the Kontron customer to give the corresponding safety instructions in the required language(s).
-
Page 39: Module Single Supply And Wide Range
The COMe Reference Carrier Type 6 is supplied via a single wide range supply between 8.5V and 18V. Please ensure that also your module supports wide range input of that range. Please check the documentation of your product if a wide range voltage input is supported. Kontron Computer-on- Modules usually supports: »... -
Page 40: Security Advice
COMe Reference Carrier Type 6 / Security Advice Security Advice To protect the external power lines to peripheral devices the customer has to take care about: - The wires to the external device have the right diameter to withstand the max. available current - The housing of the external device fulfils the fire protection requirements of IEC/EN 60950. -
Page 41: Document Revision History
Poway, CA 92064-7147 Germany Beijing 100070, P.R.China Tel.: +49 (0)8165/ 77 777 Tel.: + 86 10 63751188 Tel.: +1 888 294 4558 Fax: +49 (0)8165/ 77 219 Fax: + 86 10 83682438 Fax: +1 858 677 0898 info@kontron.com info@kontron.cn info@us.kontron.com...
