Configuring the System BIOS

24.2
The Phoenix BIOS setup utility allows you to change system behavior by modifying the BIOS
configuration. Setup-utility menus allow you to make changes and turn features on or off.
BIOS setup menus represent those found in most models of the speedMOPSlcdCE. The BIOS setup
utility for specific models can differ slightly.
Note: Selecting incorrect values can cause system boot failure. Load setup-default
values to recover by pressing <F9>.

Start Phoenix BIOS Setup Utility

24.2.1.
To start the Phoenix BIOS Setup Utility, press the <F2> key when the following string appears
during boot-up.
Press <F2> to enter Setup
The Main Menu then appears.

General Information

24.2.2.
The Setup Screen is composed of several sections:
Setup Screen
Menu Bar
Legend Bar
Item Specific Help Window
Menu Window
General Help Window
Menu Bar
The menu bar at the top of the window lists different menus. Use the left/right arrow keys to make a
selection.
Appendix B: BIOS Operation
Location
Top Lists and selects all top-level menus.
Bottom Lists setup navigation keys.
Right
Left Center Selection fields for current menu.
Overlay (center)
56
KONTRON
Function
Help for selected item.
Help for selected menu.
