Keyboard Features Submenu; Hardware Monitor Submenu - Kontron speedMOPSlcdCE User Manual

KONTRON
Parallel Port
Mode
Base I/O address
IRQ
DMA
Note: In the Option column, bold shows default settings.

Keyboard Features Submenu

24.4.7.
Feature
Numlock
Key Click
Keyboard auto- repeat rate
Keyboard auto-repeat delay
Note: In the Option column, bold shows default settings.

Hardware Monitor Submenu

24.4.8.
This submenu shows the current voltages, temperatures and the fan speed of the system.
Voltage/Temperature/Fan
VCC 3.3V Voltage
CPU Core Voltage
5Vsb Voltage
Battery Voltage
CPU Temperature
CPU Fan Speed
(not available until BIOS
revision P815R112)
speedMOPSlcdCE User's Guide
Disabled
Enabled Enabled requires end user to enter the base I/O
Auto
Output only
Bi -directional
EPP
ECP
378h, 278h
IRQ 5, IRQ 7
DMA1, DMA3
Option
Auto
On
Off
Disabled
Enabled
30/sec, 26.7/sec, 21.8/sec,
18,5/sec, 13.3/sec, 10/sec,
6/sec, 2/sec
¼ sec, ½ sec, ¾ sec, 1 sec
3.3V power plane
CPU core voltage
5V-Standby voltage
Battery voltage
CPU Temperature in °C and °F
CPU fan speed in rpm,
"no function" will be displayed on boards with passive cooling
65
Disabled turns off the port.
address and the IRQ.
Auto makes the BIOS configure the port.
Set the mode for the parallel port.
Select I/O base of port.
Select IRQ of parallel port.
Select DMA channel of port if in ECP mode.
Description
On or Off turns NumLock
on or off at boot-up.
Auto turns NumLock on if it finds a
numeric key pad.
Turns audible key click on.
Sets the number of times to repeat a
keystroke per second if you hold the
key down.
Sets the delay time after the key is
held down before it begins to repeat
the keystroke.
Explanation
Appendix B: BIOS Operation
