Connector Functions and Interface Cables

27.3
The table notes connector functions, as well as mating connectors and available cables.
Connector Function
J1 Flat-panel display
Connector
J2 CRT Monitor
Connector
J3 Fan Connector
J4, J5 Ethernet Interface
Connectors
J6A, X5 Power Connector
J6B PC/104 Bus
(AT-bus part)
J6C PC/104 Bus
(XT-bus part)
J8 PC/104-Plus Bus
(PCI part)
J11 PS/2 Mouse
Connector
J12 Keyboard and Feature
Connector
J13, J14 Serial Interfaces COM
A and COM B
Connectors
J15, J16 IDE Hard Disk
Connector
J17, J18 USB interface
Connectors
X1 Floppy Drive
Connector
X2 Sound Connector
X6 LPT Connector
speedMOPSlcdCE User's Guide
Mating Connector
-
1.25mm 6 pos.
(Molex 51021-0600 or
compatible)
1.25mm 3 pos.
(Molex 51021-0300 or
compatible)
2mm 8 pos.
(Berg 90311-008 or compatible)
2.54mm 10 pos.
(AMP 1-215882-0 or
compatible)
2.54mm 40 pos.
(EPT 962-60203-12 or
compatible for board to board
connection)
2.54mm 64 pos.
(EPT 962-60323-12 or
compatible for board to board
connection)
2mm 120pos.
(EPT 264-60303-12)
1.25mm 4 pos.
(Molex 51021-0400 or
compatible)
2.54mm 10 pos.
(AMP 1-215882-0 or
compatible)
2.54mm 10 pos.
(AMP 1-215882-0 or
compatible)
2mm 44 pos.
(Berg 89361-144 or compatible)
1.25mm 4 pos.
(Molex 51021-0400 or
compatible)
2.54mm 6 pos.
(JST XHP-6
with crimp contacts
JST SXH-001T-PO.6
Or
JST SXH-002T-PO.6)
2.54mm 26 pos.
(AMP 2-215882-6 or
compatible)
83
Available Cable
Description
KAB-JILI-????? Kontron JILI
KAB-VGA-2 For DSUB 15
(PN 96053-0000-00-0) adaptation.
KAB-MOPS-ETN1 For RJ45
(PN 96048-0000-00-0) adaptation.
KAB-MOUSE-PS2 For PS/2 mouse.
(PN 96062-0000-00-0)
KAB-KB-1 For AT -keyboard
(PN 96023-0000-00-0)
or PS/2 keyboard.
KAB-KB-PS2
(PN 96060-0000-00-0)
KAB-DSUB9-2 For DSUB 9
(PN 96017-0000-00-0) adaptation.
KAB-IDE-25 For 3.5" HDD
(PN 96020-0000-00-0)
or 2.5" HDD.
KAB-IDE-2MM
(PN 96021-0000-00-0)
KAB-USB-1 For standard
(PN 96054-0000-00-0) USB adaptation.
ADA-FLOPPY-2 For 3.5" floppy
(PN 96001-0000-00-0)
or slim-line floppy.
KAB-FLOPPY/MOPS-1
(PN 96019-0000-00-0)
KAB-SOUND-CMP Cable with open
(PN96063-0000-00-0)
KAB-DSUB25-1 For DSUB 25
(PN 96015-0000-00-0) adaptation.
Appendix E: Connector Layout
Cable
cables.
or
Or
or
ends
