KONTRON
Legend Bar
Use the keys listed in the legend bar on the bottom to make your selections or exit the current
menu. The table below describes the legend keys and their alternates.
Key
<F1> or <Alt- H>
<Esc>
 or  Arrow key
or Arrow key
<Tab> or <Shift-Tab>
<Home> or <End>
<PgUp> or <PgDn>
<F5> or <->
<F6> or <+> or <Space>
<F9>
<F10>
<Enter>
<Alt-R>
Selecting an Item
Use the or key to move the cursor to the field you want. Then use the + and - keys to select a
value for that field. Save Value commands in the Exit menu save the values displayed in all menus.
Displaying Submenus
Use the  or  key to move the cursor to the submenu you want. Then press <Enter>. A pointer
() marks all submenus.
Item Specific Help Window
The Help window on the right side of each menu displays the Help text for the selected item. It
updates as you move the cursor to each field.
General Help Window
Pressing <F1> or <ALT-F1> on a menu brings up the General Help window that describes the
legend keys and their alternates. Press <Esc> to exit the General Help window.
speedMOPSlcdCE User's Guide
Function
General Help window.
Exit menu.
Select a menu.
Select fields in current menu.
Cycle cursor up and down.
Move cursor to top or bottom of current window.
Move cursor to next or previous page.
Select previous value for the current field.
Select next value for the current field.
Load the default configuration values for this menu.
Save and exit.
Execute command or select submenu.
Refresh screen.
57 Appendix B: BIOS Operation
