Par. Parameter description
No. #
3-8* Other Ramps
3-80 Jog Ramp Time
3-81 Quick Stop Ramp Time
3-82 Quick Stop Ramp Type
3-83 Quick Stop S-ramp Ratio at Decel. Start
3-84 Quick Stop S-ramp Ratio at Decel. End
3-9* Digital Pot.Meter
3-90 Step Size
3-91 Ramp Time
3-92 Power Restore
3-93 Maximum Limit
3-94 Minimum Limit
3-95 Ramp Delay
Table 6.20
VLT Automation Low Harmonic Drive Operating Instructions
Default value
App.Dependent
App.Dependent
[0] Linear
50 %
50 %
0.10 %
1.00 s
[0] Off
100 %
-100 %
App.Dependent
®
MG34O202 - VLT is a registered Danfoss trademark
4-set-up FC 302 Change
only during
operation
All set-ups TRUE
2 set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
Conver- Type
sion
index
-2 Uint32
-2 Uint32
- Uint8
0 Uint8
0 Uint8
-2 Uint16
-2 Uint32
- Uint8
0 Int16
6 6
0 Int16
-3 TimD
