6.3.14 14-** Special Functions
Par. Parameter description
No. #
14-0* Inverter Switching
14-00 Switching Pattern
14-01 Switching Frequency
14-03 Overmodulation
14-04 PWM Random
14-06 Dead Time Compensation
14-1* Mains On/Off
14-10 Mains Failure
14-11 Mains Voltage at Mains Fault
6 6
14-12 Function at Mains Imbalance
14-13 Mains Failure Step Factor
14-14 Kin. Backup Time Out
14-2* Trip Reset
14-20 Reset Mode
14-21 Automatic Restart Time
14-22 Operation Mode
14-23 Typecode Setting
14-24 Trip Delay at Current Limit
14-25 Trip Delay at Torque Limit
14-26 Trip Delay at Inverter Fault
14-28 Production Settings
14-29 Service Code
14-3* Current Limit Ctrl.
14-30 Current Lim Ctrl, Proportional Gain
14-31 Current Lim Ctrl, Integration Time
14-32 Current Lim Ctrl, Filter Time
14-35 Stall Protection
14-4* Energy Optimising
14-40 VT Level
14-41 AEO Minimum Magnetisation
14-42 Minimum AEO Frequency
14-43 Motor Cosphi
14-5* Environment
14-50 RFI Filter
14-51 DC Link Compensation
14-52 Fan Control
14-53 Fan Monitor
14-55 Output Filter
14-56 Capacitance Output Filter
14-57 Inductance Output Filter
14-59 Actual Number of Inverter Units
Table 6.33
110
VLT Automation Low Harmonic Drive Operating Instructions
Default value
null
null
[1] On
[0] Off
[1] On
[0] No function
App.Dependent
[0] Trip
1.0 N/A
60 s
[0] Manual reset
App.Dependent
[0] Normal operation
null
60 s
60 s
App.Dependent
[0] No action
0 N/A
100 %
0.020 s
1.0 ms
[1] Enabled
66 %
App.Dependent
10 Hz
App.Dependent
[1] On
[1] On
[0] Auto
[1] Warning
[0] No Filter
App.Dependent
App.Dependent
App.Dependent
®
MG34O202 - VLT is a registered Danfoss trademark
4-set-up FC 302 Change
only during
operation
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
2 set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up x FALSE
1 set-up TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
1 set-up x FALSE
Conver- Type
sion
index
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
0 Uint16
- Uint8
-1 Uint8
0 Uint8
- Uint8
0 Uint16
- Uint8
- Uint8
0 Uint8
0 Uint8
0 Uint8
- Uint8
0 Int32
0 Uint16
-3 Uint16
-4 Uint16
- Uint8
0 Uint8
0 Uint8
0 Uint8
-2 Uint16
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
-7 Uint16
-6 Uint16
0 Uint8
