Danfoss VLT AutomationDrive FC 300 Operating Instructions Manual page 85

How to Programme the Low Ha...
[154] ATEX ETR freq.
warning
[188] AHF Capacitor
Connect
[189] External fan
control
6 6
5-40 Function Relay
Array [9]
(Relay 1 [0], Relay 2 [1], Relay 3 [2] (MCB 113), Relay 4 [3] (MCB
113), Relay 5 [4] (MCB 113), Relay 6 [5] (MCB 113), Relay 7 [6]
(MCB 105), Relay 8 [7] (MCB 105), Relay 9 [8] (MCB 105))
Option:
[0] No operation
*
[1] Control ready
[2] Drive ready
[3] Drive rdy/rem ctrl
[4] Enable / no warning Ready for operation. No start or stop
[5] VLT running
[6] Running / no
warning
[7] Run in range/no
warn
[8] Run on ref/no warn
[9] Alarm
84
VLT Automation Low Harmonic Drive Operating Instructions
Selectable if 1-90 Motor Thermal Protection
is set to [20] or [21]. If the warning 165
ATEX ETR freq.lim.warning is active, the
output will be 1.
The capacitors will be turned on at 20%
(hysteresis of 50% gives an interval of
10% - 30%). The capacitors will be discon-
nected below 10%. The off delay is 10s
and will restart if the nominal power goes
above 10% during the delay. 5-80 AHF
Cap Reconnect Delay is used to guarantee
a minimum off-time for the capacitors.
The internal logics for the internal fan
control is transferred to this output to
make it possible to control an external
fan (relevant for HP duct cooling).
Function:
All digital and relay outputs are
default set to "No Operation".
The control card is ready. E.g.:
Feedback from a drive where the
control is supplied by an external 24
V (MCB 107) and the main power to
drive is not detected.
Drive is ready to operate. Mains and
control supplies are OK.
The frequency converter is ready for
operation and is in Auto On mode
commands have been applied (start/
disable). No warnings are active.
Motor is running, and shaft torque
present.
Output speed is higher than the
speed set in 1-81 Min Speed for
Function at Stop [RPM] Min Speed for
Function at Stop [RPM]. The motor is
running and no warnings.
Motor is running within the
programmed current and speed
ranges set in 4-50 Warning Current
Low and 4-53 Warning Speed High.
No warnings.
Motor runs at reference speed. No
warnings.
An alarm activates the output. No
warnings
MG34O202 - VLT
5-40 Function Relay
Array [9]
(Relay 1 [0], Relay 2 [1], Relay 3 [2] (MCB 113), Relay 4 [3] (MCB
113), Relay 5 [4] (MCB 113), Relay 6 [5] (MCB 113), Relay 7 [6]
(MCB 105), Relay 8 [7] (MCB 105), Relay 9 [8] (MCB 105))
Option:
[10] Alarm or warning
[11] At torque limit
[12] Out of current
range
[13] Below current, low
[14] Above current, high
[15] Out of speed range
[16] Below speed, low
[17] Above speed, high
[18] Out of feedb. range
[19] Below feedback, low Feedback is below the limit set in
[20] Above feedback,
high
[21] Thermal warning
[22] Ready,no thermal W The frequency converter is ready for
[23] Remote,ready,no TW The frequency converter is ready for
[24] Ready, Voltage OK
[25] Reverse
®
is a registered Danfoss trademark
Function:
An alarm or a warning activates the
output.
The torque limit set in 4-16 Torque
Limit Motor Mode or 4-17 Torque
Limit Generator Mode has been
exceeded.
The motor current is outside the
range set in 4-18 Current Limit.
Motor current is lower than set in
4-50 Warning Current Low.
Motor current is higher than set in
4-51 Warning Current High.
Output speed/frequency is outside
the frequency range set in
4-52 Warning Speed Low and
4-53 Warning Speed High.
Output speed is lower than the
setting in 4-52 Warning Speed Low
Output speed is higher than the
setting in 4-53 Warning Speed High.
Feedback is outside the range set in
4-56 Warning Feedback Low and
4-57 Warning Feedback High.
4-56 Warning Feedback Low.
Feedback is above the limit set in
4-57 Warning Feedback High.
Thermal warning turns on when the
temperature exceeds the limit either
in motor, frequency converter, brake
resistor, or connected thermistor.
operation and there is no over-
temperature warning.
operation and is in Auto On mode.
There is no over-temperature
warning.
The frequency converter is ready for
operation and the mains voltage is
within the specified voltage range
(see General Specifications section in
Design Guide).
Logic '1' when CW rotation of the
motor. Logic '0' when CCW rotation
