6.3 Parameter Lists - Frequency Converter

Changes during operation
"TRUE" means that the parameter can be changed while
the frequency converter is in operation and "FALSE" means
that the it must be stopped before a change can be made.
Conv. index
Conv. factor
Table 6.13
6 6
Data Description
type
2 Integer 8
3 Integer 16
4 Integer 32
5 Unsigned 8
6 Unsigned 16
7 Unsigned 32
9 Visible String
33 Normalized value 2 bytes
35 Bit sequence of 16 boolean variables
54 Time difference w/o date
Table 6.14
See the frequency converter Design Guide for further
information about data types 33, 35 and 54.
Parameters for the frequency converter are grouped into
various parameter groups for easy selection of the correct
parameters for optimized operation of the frequency
converter.
0-** Operation and Display parameters for basic frequency
converter settings
1-** Load and Motor parameters, includes all load and
motor related parameters
2-** Brake parameters
3-** References and ramping parameters, includes DigiPot
function
4-** Limits Warnings, setting of limits and warning
parameters
5-** Digital inputs and outputs, includes relay controls
6-** Analog inputs and outputs
90
VLT Automation Low Harmonic Drive Operating Instructions
100 67 6 5
1 1/60 1000000 100000 10000
MG34O202 - VLT
4-Set-up
'All set-up': the parameters can be set individually in each
of the four set-ups, i.e. one single parameter can have four
different data values.
'1 set-up': data value will be the same in all set-ups.
Conversion index
This number refers to a conversion figure used when
writing or reading to and from the frequency converter.
4 3 2 1 0
1000 100 10 1
7-** Controls, setting parameters for speed and process
Type
controls
Int8
8-** Communication and option parameters, setting of FC
Int16
RS485 and FC USB port parameters.
Int32
Uint8
Uint16 9-** Profibus parameters
Uint32
VisStr
10-** DeviceNet and CAN Fieldbus parameters
N2
V2
12-** Ethernet parameters
TimD
13-** Smart Logic Control parameters
14-** Special function parameters
15-** Drive information parameters
16-** Read out parameters
17-** Encoder Option parameters
18-** Data Readouts 2
30-** Special Features
32-** MCO 305 Basic parameters
33-** MCO 305 Advanced parameters
34-** MCO Data Readout parameters
35-** Sensor Input Option
®
is a registered Danfoss trademark
-1 -2 -3 -4
0.1 0.01 0.001 0.0001 0.00001 0.000001
-5 -6
