[74] Logic Rule 4 See parameter group 13-4*. If Logic Rule
4 is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
[75] Logic Rule 5 See parameter group 13-4*. If Logic Rule
5 is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
[80] SL Digital See 13-52 SL Controller Action. The output
Output A will go high whenever the Smart Logic
Action [38] Set dig. out. A high is
executed. The output will go low
whenever the Smart Logic Action [32] Set
dig. out. A low is executed.
[81] SL Digital See 13-52 SL Controller Action. The input
Output B will go high whenever the Smart Logic
Action [39] Set dig. out. A high is
executed. The input will go low whenever
the Smart Logic Action [33] Set dig. out. A
low is executed.
[82] SL Digital See 13-52 SL Controller Action. The input
Output C will go high whenever the Smart Logic
Action [40] Set dig. out. A high is
executed. The input will go low whenever
the Smart Logic Action [34] Set dig. out. A
low is executed.
[83] SL Digital See 13-52 SL Controller Action. The input
Output D will go high whenever the Smart Logic
Action [41] Set dig. out. A high is
executed. The input will go low whenever
the Smart Logic Action [35] Set dig. out. A
low is executed.
[84] SL Digital See 13-52 SL Controller Action. The input
Output E will go high whenever the Smart Logic
Action [42] Set dig. out. A high is
executed. The input will go low whenever
the Smart Logic Action [36] Set dig. out. A
low is executed.
[85] SL Digital See 13-52 SL Controller Action. The input
Output F will go high whenever the Smart Logic
Action [43] Set dig. out. A high is
executed. The input will go low whenever
the Smart Logic Action [37] Set dig. out. A
low is executed.
[120] Local reference Output is high when 3-13 Reference Site =
active [2] Local or when 3-13 Reference Site = [0]
Linked to hand auto at the same time as
the LCP is in [Hand on] mode.
VLT Automation Low Harmonic Drive Operating Instructions
[121] Remote
[122] No alarm
[123] Start command
[124] Running
[125] Drive in hand
[126] Drive in auto
[151] ATEX ETR cur.
[152] ATEX ETR freq.
[153] ATEX ETR cur.
®
MG34O202 - VLT is a registered Danfoss trademark
Reference site set
in 3-13 Reference
Site
Reference site:
Local
3-13 Reference Site
[2]
Reference site:
Remote
3-13 Reference Site
[1]
Reference site:
Linked to Hand/
Auto
Hand
Hand -> off
Auto -> off
Auto
Table 6.10
Output is high when 3-13 Reference Site
reference =[1] Remote or [0] Linked to hand/auto
active while the LCP is in [Auto on] mode. See
above.
Output is high when no alarm is present.
Output is high when there is an active
active Start command (i.e. via digital input bus
connection or [Hand on] or [Auto on]),
and no Stop or Start command is active.
Output is high when the frequency
reverse converter is running counter clockwise
(the logical product of the status bits
'running' AND 'reverse').
Output is high when the frequency
mode converter is in [Hand on] mode (as
indicated by the LED light above [Hand
on]).
Output is high when the frequency
mode converter is in [Hand on] mode (as
indicated by the LED light above [Auto
on]).
Selectable if 1-90 Motor Thermal Protection
alarm is set to [20] or [21]. If the alarm 164
ATEX ETR cur.lim.alarm is active, the
output will be 1.
Selectable if 1-90 Motor Thermal Protection
alarm is set to [20] or [21]. If the alarm 166
ATEX ETR freq.lim.alarm is active, the
output will be 1.
Selectable if1-90 Motor Thermal Protection
warning is set to [20] or [21] ]. If the alarm 163
ATEX ETR cur.lim.warning is active, the
output will be 1.
Local Remote
referenc reference
e active
active [121]
[120]
1 0
0 1
6
1 0
1 0
0 0
0 1
83
