5-40 Function Relay
Array [9]
(Relay 1 [0], Relay 2 [1], Relay 3 [2] (MCB 113), Relay 4 [3] (MCB
113), Relay 5 [4] (MCB 113), Relay 6 [5] (MCB 113), Relay 7 [6]
(MCB 105), Relay 8 [7] (MCB 105), Relay 9 [8] (MCB 105))
Option:
[64]
Comparator 4
[65]
Comparator 5
6
6
[70]
Logic rule 0
[71]
Logic rule 1
[72]
Logic rule 2
[73]
Logic rule 3
[74]
Logic rule 4
[75]
Logic rule 5
[80]
SL digital output A
[81]
SL digital output B
[82]
SL digital output C
86
VLT Automation Low Harmonic Drive Operating Instructions
Function:
SLC is TRUE, the output will go high.
Otherwise, it will be low.
See parameter group 13-1* (Smart
Logic Control). If Comparator 4 in
SLC is TRUE, the output will go high.
Otherwise, it will be low.
See parameter group 13-1* (Smart
Logic Control). If Comparator 5 in
SLC is TRUE, the output will go high.
Otherwise, it will be low.
See parameter group 13-4*(Smart
Logic Control). If Logic Rule 0 in SLC
is TRUE, the output will go high.
Otherwise, it will be low.
See parameter group 13-4*(Smart
Logic Control). If Logic Rule 1 in SLC
is TRUE, the output will go high.
Otherwise, it will be low.
See parameter group 13-4*(Smart
Logic Control). If Logic Rule 2 in SLC
is TRUE, the output will go high.
Otherwise, it will be low.
See parameter group 13-4*(Smart
Logic Control). If Logic Rule 3 in SLC
is TRUE, the output will go high.
Otherwise, it will be low.
See parameter group 13-4*(Smart
Logic Control). If Logic Rule 4 in SLC
is TRUE, the output will go high.
Otherwise, it will be low.
See parameter group 13-4*(Smart
Logic Control). If Logic Rule 5 in SLC
is TRUE, the output will go high.
Otherwise, it will be low.
See 13-52 SL Controller Action.
Output A is low on Smart Logic
Action [32]. Output A is high on
Smart Logic Action [38].
See 13-52 SL Controller Action.
Output B is low on Smart Logic
Action [33]. Output B is high on
Smart Logic Action [39].
See 13-52 SL Controller Action.
Output C is low on Smart Logic
Action [34]. Output C is high on
Smart Logic Action [40].
®
MG34O202 - VLT
5-40 Function Relay
Array [9]
(Relay 1 [0], Relay 2 [1], Relay 3 [2] (MCB 113), Relay 4 [3] (MCB
113), Relay 5 [4] (MCB 113), Relay 6 [5] (MCB 113), Relay 7 [6]
(MCB 105), Relay 8 [7] (MCB 105), Relay 9 [8] (MCB 105))
Option:
[83]
SL digital output D
[84]
SL digital output E
[85]
SL digital output F
[120] Local ref active
[121] Remote ref active
[122] No alarm
[123] Start command
activ
is a registered Danfoss trademark
Function:
See 13-52 SL Controller Action.
Output D is low on Smart Logic
Action [35]. Output D is high on
Smart Logic Action [41]
See 13-52 SL Controller Action.
Output E is low on Smart Logic
Action [36]. Output E is high on
Smart Logic Action [42].
See 13-52 SL Controller Action.
Output F is low on Smart Logic
Action [37]. Output F is high on
Smart Logic Action [43].
Output is high when 3-13 Reference
Site = [2] Local or when
3-13 Reference Site = [0] Linked to
hand auto at the same time as the
LCP is in [Hand on] mode.
Reference site
Local
Remote
set in
referen
reference
3-13 Reference
ce
active
Site
active
[121]
[120]
Reference site:
1
0
Local
3-13 Reference
Site [2]
Reference site:
0
1
Remote
3-13 Reference
Site [1]
Reference site:
Linked to
Hand/ Auto
Hand
1
0
Hand -> off
1
0
Auto -> off
0
0
Auto
0
1
Table 6.11
Output is high when 3-13 Reference
Site = Remote [1] or Linked to hand/
auto [0] while the LCP is in [Auto
on] mode. See above.
Output is high when no alarm is
present.
Output is high when the Start
command high (i.e. via digital input,
