How to Install
4, 8, 9
5
6
Illustration 4.29 Inverter Cabinet, frame size F18
Table 4.23
1) External Temperature Monitoring
2) AUX Relay
01 02 03
04 05 06
3) NAMUR
4) AUX Fan
100 101 102 103
L1 L2 L1 L2
5) Brake
-R +R
81 82
Table 4.24
VLT Automation Low Harmonic Drive Operating Instructions
2
1
6) Motor
96
T1
7) NAMUR Fuse. See 4.6.14 Fuses for part numbers
8) Fan Fuses. See 4.6.14 Fuses for part numbers
9) SMPS Fuses. See 4.6.14 Fuses for part numbers
®
MG34O202 - VLT is a registered Danfoss trademark
U V W
97 98
T2 T3
4 4
Section shown
↓
