Par. Parameter description
No. #
15-9* Parameter Info
15-92 Defined Parameters
15-93 Modified Parameters
15-98 Unit Identification
15-99 Parameter Metadata
Table 6.53

6.4.6 Data Readouts 16-**

Par. Parameter description
No. #
16-0* General Status
16-00 Control Word
16-03 Status Word
16-3* AF Status
16-30 DC Link Voltage
16-34 Heatsink Temp.
16-35 Inverter Thermal
16-36 Inv. Nom. Current
16-37 Inv. Max. Current
16-39 Control Card Temp.
16-40 Logging Buffer Full
16-49 Current Fault Source
16-6* Inputs & Outputs
16-60 Digital Input
16-66 Digital Output [bin]
16-71 Relay Output [bin]
16-8* Fieldbus & FC Port
16-80 Fieldbus CTW 1
16-84 Comm. Option STW
16-85 FC Port CTW 1
16-9* Diagnosis Readouts
16-90 Alarm Word
16-91 Alarm Word 2
16-92 Warning Word
16-93 Warning Word 2
16-94 Ext. Status Word
Table 6.54
VLT Automation Low Harmonic Drive Operating Instructions
Default value 4-set-up
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
Default value
0 N/A
0 N/A
0 V
0 °C
0 %
ExpressionLimit
ExpressionLimit
0 °C
[0] No
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
®
MG34O202 - VLT is a registered Danfoss trademark
FC 302 Change
only during
operation
FALSE
FALSE
FALSE
FALSE
4-set-up FC 302 Change
only during
operation
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
Conver- Type
sion index
0 Uint16
0 Uint16
0 VisStr[40]
0 Uint16
Conver- Type
sion
index
0 V2
0 V2
0 Uint16
100 Uint8
0 Uint8
-2 Uint32
-2 Uint32
100 Uint8
- Uint8
0 Uint8
0 Uint16
0 Int16
0 Int16
0 V2
0 V2
0 V2
0 Uint32
0 Uint32
0 Uint32
0 Uint32
0 Uint32
129
6 6
