Log Enable
(Ctrl+A)
Instrument Error
Status
Instrument
Realtime Clock
Device
... Configuration
You can expand the Device pull-down menu by pressing the F12 function key (on your computer keyboard) prior to
pulling down the menu. After pressing F12, the pull-down menu will show a listing entitled "Configuration." The
expanded-menu setting is not saved in the configuration file when exiting ChartView. If the expanded menu is
desired, you must press F12 each time you start ChartView. This expanded menu is typically not used by the
operator. The Raw Thermocouple Input and Raw Temperature Sensor Input selections primarily exist as an aid in
troubleshooting by experienced technicians.
4-26 ChartView Software Reference
Once an alarm log file exists, log enable can be used to activate the logging process; or to disable an
active log. A check-mark ( ) preceding Log Enable indicates that the log is active. No check-mark
present indicates the alarm log has not been enabled.
Brings up the Device Error Status dialog box. This box lists existing error types, including invalid
command and channel configuration errors.
Brings up the Device System Time dialog box. You can adjust the time and date settings from this
box.
A Device Expanded Menu
Device Status Dialog Boxes
(obtained with use of the F12 Key)
