Configuration Aspects for Programmers
With Alarm Stamping:
PRINT#1, "OUTPUT07;A#1X"
PRINT#1, "OUTPUT07;R1X"
PRINT#1, "ENTER07"
INPUT A$
....+0234.20-0019.40+0001.40+0023.60 005 128 032 066

Digital Input Stamping (I#)

Digital Input Stamping (
the scan. This is accomplished by a digital input "ON" (1) or "OFF" (0) code appended to the scan in real time.
Digital Input Stamping can be enabled with the
there are 8 digital inputs.
Note: Digital Input Stamping is not valid in high-speed, single channel mode (burst mode).
Examples of
I#
Without Digital Input Stamping (default):
PRINT#1, "OUTPUT07;I#0X"
PRINT#1, "OUTPUT07;R1X"
PRINT#1, "ENTER07"
INPUT A$
....+0234.20-0019.40+0001.40+0023.60
B-16
' Enable alarm stamping
. ' Configure and start an acquisition
' Request the next scan in the buffer
' Retrieve it
'
) allows you to see whether a digital input was "active" or "inactive" at the time of
I#
command follow.
.
command and disabled with the
I#1
' Disable digital input stamping
' Configure and start an acquisition
' Request the next scan in the buffer
' Retrieve it
'
Appendix B
command. Note that
I#0
