Calibration of Main Unit

Offset Calibration of Main Unit

Required Equipment
- Shorting bar, or 3 linked banana plugs (see following figure)
- Calibration Card (installed in bottom slot, slot #1, of the main unit)
6-6 Calibration
Do not install or remove any cards from the main unit, or from its expansion chassis
unless the unit is powered "OFF" and has no power sources connected to it.
Use approved ESD precautions, including static-free work area and grounded wrist
strap, when handling circuit boards and electronic components. Failure to do so
could cause equipment damage due to electrostatic discharge.
CAUTION CAUTION CAUTION CAUTION
CAUTION CAUTION CAUTION CAUTION
ChartScan User's Manual
