= Mouse, = Arrow Keypads ,
1 Group Select
2 Start Charts &
Indicators
3 Pause Charts
4 Stop Charts
5 Scroll Faster
6 Scroll Slower
7 Display Configuration
8 Channel Configuration
9 PostView post-acq
data viewer
10 Arm Acquisition
11 Disarm ...
12 Print Charts
13 Chart Max. Scale
Value (Grid Limit Line)
1-8 ChartScan – Unit Startup and ChartView Tutorial
ChartView Main Window
ChartView Main Window Control Options
= PageUp/PageDown Keypads
14
,
Ctrl+G,
or or
15
F5
or,
16
F7
or,
17
F6
or,
18
Ctrl+Z
or,
19
Ctrl+X
or,
20
or, Pointer over chart
and "right-click"
Current group will be
selected.
21
22
or, Windows Pull-
down menu
23
Ctrl+T
or,
24
Ctrl+Y
or,
25
Ctrl+P
or,
From Chart Pull-down
menu or Chart Setup
Dialog Box
Channel Selection
Multiply (x2)
Present Value of Selected Channel
Center (Value at Chart Mid-Line)
Units/Division
(Vertical increment per one grid box)
Chart Min. Scale Value (Grid Limit
Line)
Divide (÷2)
Time Scroll (hr:min:sec)
Status Message Box
Time/Division (Chart Speed),
the Horizontal increment per grid box
Status LEDs
Chart Display
Double-click left mouse button in selected chart to zoom in or zoom
back out. Right-click to bring up Chart Setup Dialog Box with the
current group and target chart selected.
or,
or,[Tab to and hit
Spacebar]
N/A
or, , or type-in
or, , or type-in
From Chart Pull-down
menu or Chart Setup
Dialog Box
or, [Tab to and hit
Spacebar]
Thru Pull-Down Menus
only
N/A
Ctrl+Z (Faster)
Ctrl+X (Slower)
N/A
