16-Channel Signal Conditioning Cards (Optional)
Low-voltage
with removable
terminal block input module
Low-voltage
with BNC input
module
Low-voltage
with safety jack
input module
Isolated TC/voltage
plug type input module
Isolated high-voltage
safety jack input module
Cables
CA-7-3,
Shielded IEEE 488 cable, 6 ft.
CA-47,
Computer-to-ChartScan Cable
PC/AT/XT serial port (9- & 25-pin sub D) to ChartScan (9-pin sub D)
RS-232/422 cable, 6 ft.
Note: A 10BASE-T cable and 10BASE-T crossover adapter are included
with the optional Net232 Ethernet/RS-232 converter.
Additional Hardware Options
4-slot expansion chassis
Memory expansion options:
1 Mbyte, 4 Mbyte, or 8 Mbyte
IEEE 488 interface card (see important notice, below)
16 output CSN/Relay card
Net232, Ethernet/RS-232 Converter
An IOtech Personal488 product is required for
IEEE 488 operation with ChartView. A device
named WAVE must be configured in IOtech
Driver 488/W31, /W95, or /WNT (when available).

ChartScan Specifications

If equipment is used in any manner not specified in this manual, or if specification limits
are exceeded, the function of the equipment, as well as the protection provided by it,
may be impaired.
NOTE: Specifications for signal conditioning cards and for the ChartScan Expansion Chassis appear in their
respective sections of this manual.
Measurement Parameters
A/D resolution
Accuracy (with type J TC)
TCs supported
DCV
ACV
Ch-to-ch isolation
Ch-to-system isolation
AC line rejection
Scanning Parameters
Switching Technology
Max scan rate
Max single-ch scan rate
Min channel configuration
Max channel configuration
General Information
(CSN14/LV/T)
(CSN14/LV/B)
(CSN14/LV/S)
(CSN14/TC/P)
with
(CSN14/HV/S)
with
CAUTION CAUTION CAUTION CAUTION
16 bit w/over sampling
± 0.5°C
J,K,T,E,R,S,B,N
3
3
500 V or 200 V
500 V
3
mechanical relays
147 chs. per sec.
20 Khz
16 channels
128 channels
ChartScan User's Manual 2-3
