Appendix C

Configuring Power-Up State

ChartScan has an internally stored factory default configuration that can be recalled at any time. You can
program the ChartScan to power-up in a "user-defined" state, or if desired, can configure the unit to power-up
with the default configuration.
During normal operations the factory defaults may be recalled by issuing the Restore Factory Defaults (*F)
command. When this command is processed, ChartScan loads the factory default configuration and operates
accordingly. This command, however, may not be issued while an acquisition is currently configured.
ChartScan is usually configured to power-up with the last known configuration (from when the unit was
powered-down). Last-configuration power-ups will also occur when a Power-On Reset (*R ) command is used.
You can configure the unit such that it will always power-up with the factory default configuration by issuing the
Power-up Settings (*S1) command. Note that issuing an *S0 (power-up under last-known configuration)
command causes the unit to power up under the last known configuration.
Note:
The following table lists the execution steps and effects when the ChartScan is configured to power-up under the
factory default configuration.
Step
1
2
3
4
5
6
7
8
9
10
11
12
13
ChartScan User's Manual
Configuring ChartScan to power-up under the factory defaults or recalling the factory default
settings will not affect pre-existing calibration factors of the ChartScan or its slave units.
Command Effect
Set general response Term. to CR-LF/EOI. All others to None
Q7,0,0,0,0
Set the User Term. to ASCII code 00 (Hex) NUL
V0
Set the data format to Engr. Units — Degrees C
F0,0
Set SRQ (SRE) Mask to 000
M0
Set Event Status Enable (ESE) to 000
N0
Un-configure all channels
*C
Set acquisition counts to all 0
Y0,0,0
Set both timebase intervals to 0.1 seconds
I00:00:00.1,00:
00:00.1
Un-configure level
L1, 0,0
Un-configure acquisition triggering
T0,0,0,0
Set measuring mode to line cycle integration/high speed multi-channel
M#0
mode
Set burst mode frequency to 20kHz
F#20000.0
Set sampling weight to 32
W#32
