ChartScan Program Examples
Using the U6 query, the controller gets the trigger block string, which, among other things, supplies the
block complete flag, indicating the state of the present trigger block. The block is marked complete when
the last post-stop scan is recorded into the buffer.
Using the U$ string which still contains the trigger block status string, the number of scans available in the
buffer is calculated. The R2 command is then used to retrieve the data in the ChartScan's internal buffer.
'Query the ChartScan for the # of scans available in the Buffer
NEXT i
After all 5 trigger blocks have been collected, the unit is disarmed by sending the T command.
PRINT #1, "OUTPUT 07;T0,0,0,0X"
Configure for 12 Channels with Continuous Binary Upload using
CONTIN_D.BAS
This program configures the ChartScan for 12 Channels and allows the system to continuously upload
binary data to disk when the buffer is 75% full.
'Establish communication with the DRIVER488
OPEN "\DEV\IEEEOUT" FOR OUTPUT AS #1
IOCTL #1, "BREAK"
PRINT #1, "RESET"
OPEN "\DEV\IEEEIN" FOR INPUT AS #2
PRINT #1, "TIMEOUT 5"
PRINT #1, "ERROR ON"
PRINT #1, "FILL ERROR"
PRINT #1, "TERM IN LF EOI"
OPEN "Chrtscan.DAT" FOR OUTPUT AS #3
s! = 4096
DataBuffer$ = SPACE$(s!)
DIM DataBuffer$(s!)
DEF FNPEEKW (addr) = PEEK(addr) + 256 * PEEK(addr + 1)
D-14
PRINT "Waiting for completion of Block "; i; ".."
DO
PRINT #1, "OUTPUT 07;U6X"
PRINT #1, "ENTER 07"
LINE INPUT #2, U$
UA$ = MID$(U$, 86, 2)
LOOP UNTIL UA$= "1"
PRINT "The ChartScan is done with Block"; i; "and has re-armed itself"
UAT$ = MID$(U$, 9, 7)
PRINT UAT$
PRINT "The ChartScan collected a total of "; VAL(UAT$); " scans"
UA$ = MID$(U$, 18, 7)
PRINT UA$
PRINT "Pre-Triggered scans :"; VAL(UA$)
UA$ = MID$(U$, 47, 8)
PRINT "Post-Triggered scans :"; VAL(UA$)
UAS$ = MID$(U$, 77, 8)
PRINT "Post-stop-Triggered scans :"; VAL(UAS$) - VAL(UA$)
'Upload Block
PRINT "Uploading trigger block"; i
PRINT #1, "OUTPUT 07;R2X"
FOR c = 1 TO VAL(UAT$)
PRINT #1, "ENTER 07"
LINE INPUT #2, SCAN$
NEXT c
PRINT "Block "; i; " is read."
'number of bytes to be transferred at a time
'output data file Dimensions
