Access Control - TP-Link TL-WR841HP User Manual

For example: If you desire that the child PC with MAC address 00-11-22-33-44-AA can access
www.tp-link.com on Saturday only, while the parent PC with MAC address 00-11-22-33-44-BB
is without any restriction, you should follow the settings below.
Click "Parental Control" menu on the left to enter the Parental Control Settings page.
1.
Check Enable and enter the MAC address 00-11-22-33-44-BB in the MAC Address of
Parental PC field.
Click "Advanced→Access Control→Schedule" on the left to enter the Schedule Settings
2.
page. Click Add New... button to create a new schedule with Schedule Description is
Schedule_1, Day is Sat and Time is all day-24 hours.
Click "Parental Control" menu on the left to go back to the Add or Modify Parental
3.
Controls Entry page:
1. Click Add New... button.
2. Enter 00-11-22-33-44-AA in the MAC Address of Child PC field.
Enter "Allow tp-link" in the Website Description field.
3.
Enter "www.tp-link.com" in the Allowed Website Name field.
4.
Select "Schedule_1" you create just now from the Effective Time drop-down list.
5.
6. In Status field, select Enable.
4. Click Save to complete the settings.
Then you will go back to the Parental Control page and see the following list.

3.4.10 Access Control

There are four submenus under the Access Control menu: Rule, Host, Target and Schedule.
Click any of them, and you will be able to configure the corresponding function.
TL-WR841HP 300Mbps High Power Wireless N Router
-62-
